Truck Slider To Canopy Slider Boot
How to Choose the Right Rubber Boot Seal
You can acquire rubber boot material for your special project. This seal is manufactured from robust EPDM synthetic rubber compound and uses a pliable spring steel clip for attaching to any flange. This material is sold by the foot. To decide how much you require measure the distance around your cab opening. You have 3 alternatives of rubber to make use of for sealing your cabs together.
Tips for Getting the Right Fit
To find how much you want measure the space around your cab opening. It is essential that both openings are perfectly the matching size. Make sure to measure the opening before ordering. Every installation is different.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is designed to resist severe conditions such as cold. It's ideal for both off-grid builds. Compared to cheaper seals, this material performs better. It's a solid choice for anyone looking to protect their truck cab connection with a dependable sealing solution.
Truck Slider To Canopy Slider Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Affordable, High-Value Solution | Great quality at a competitive price point | Cost-effective choice for budget-conscious builders |
| Silicone-Friendly Seam Sealing | Easy to seal end joints with a small bead of silicone | Ensures total waterproofing where ends come together |
| Made in the USA | High manufacturing standards and local support | Ideal for buyers who value American-made products |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- How do I measure for a truck slider to canopy slider boot?
To install a , use a flexible tape to measure the full perimeter of the opening. Add 1–2 inches for adjustment or overlap.
- Will the Accordion Boot or Compression Boot Gasket Material work if my fiberglass shell opening is bigger than my truck window?
In order for the accordion boot to work, both openings must be the exact size. If the fiberglass shell opening is larger, use the compression boot instead.
- I have a truck that I want to install a camper shell on. The shell has a slider and I will need to remove the rear cab window. Is there a procedure when using a boot that insures a watertight seal?
To insure a water tight seal you should consider the accordion boot. In order to use the accordion boot there are a few condition that need to be met.
- 1) Both opening must be the exact same size
- 2) there must be some sort of thin wall or flange to attach the boot. This can be the fiberglass wall or pinch weld around the window opening.
- 3) Both windows will need to be removed.
