Truck Slide Rear Window Pass Style
How to Choose the Right Rubber Boot Seal
You can obtain rubber boot material for your special project. This seal is extruded from resilient EPDM synthetic rubber compound and has a bendable spring steel clip for attaching to any flange. This material is available by the foot. To determine how much you require measure the distance encircling your cab opening. You get 3 alternatives of rubber to employ for sealing your cabs together.
Tips for Getting the Right Fit
To ascertain how much you require measure the distance around your cab opening. It is important that both openings are precisely the equal size. Make sure to measure the opening before ordering. Every installation is different.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is essential for your vehicle project. This rubber boot excels due to its superior construction and real-world reliability. We take pride on providing products that surpass your expectations for long-term satisfaction. Don't settle for flimsy seals, upgrade to one that's engineered for adventure.
Truck Slide Rear Window Pass Style Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Affordable, High-Value Solution | Great quality at a competitive price point | Cost-effective choice for budget-conscious builders |
| Adapts to Slightly Uneven Openings | Flexible enough to seal even when openings aren’t perfectly aligned | Even though it is best that the opening match exactly there is some wiggle room to make minor adjustments for custom truck and canopy installations |
| Powder-Coated Friendly Channel | Seals well even on painted or coated surfaces | Ensures compatibility with modified or custom trucks |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Can I install the boot myself?
Yes, most customers install the boot themselves with basic tools. A helper and soapy water can make the process easier.
- Does the truck slide rear window pass style require glue to install?
No glue is required. The truck slide rear window pass style has a spring clip embedded in the EPDM rubber that clamps onto a thin flange. You can optionally glue the seam using cyanoacrylate (SuperGlue), but avoid petroleum-based adhesives.
- I have a truck with a wood framed utility box and would like join the cab and box using the accordion boot. How to I attach the boot?
You will not be able to attach the boot material to the wood, It is too thick. The best way to remedy this is to add a flange to the box. This could be done with steel or aluminum flat bar, or something similar (i.e. sheet metal, fiberglass), installed around the perimeter of the opening to allow the boot to attach to the box
