Truck Rear Sleder Window Boot
How to Choose the Right Rubber Boot Seal
You can purchase rubber boot material for your special project. This seal is extruded from resilient EPDM synthetic rubber substance and contains a pliable spring steel clip for affixing to any flange. This material is available by the foot. To specify how much you need measure the distance encircling your cab opening. You get 3 alternatives of rubber to use for waterproofing your cabs together.
Quick and Easy Installation
Installing this rubber boot is user-friendly and requires minimal tools. Just secure the seal firmly onto the thin wall of the window or pass through opening. This creates a watertight connection between the two units. Regardless of whether you're traveling, this seal prevents wind and ensures interior comfort during your journey.
Universal Fit: Compatible Rubber Seals for Trucks and Rigs
This rubber boot seal is widely used in vehicle sealing applications. It's compatible with most full-size trucks. Whether you're retrofitting a camper shell or building a personalized rig, this seal offers flexible fitment and dependable performance for your cab connection project.
Truck Rear Sleder Window Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| UV & Weather Resistant | Withstands sun, rain, and temperature changes without cracking | Long-term durability for vehicles stored outdoors |
| Adapts to Slightly Uneven Openings | Flexible enough to seal even when openings aren’t perfectly aligned | Even though it is best that the opening match exactly there is some wiggle room to make minor adjustments for custom truck and canopy installations |
| Weather-Tested Seal | Handles rainstorms without leaks or performance loss | Reliable weather barrier for daily-use trucks or RVs |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- How much will I need?
This material is sold by the foot. Unlike other companies that force you to buy more than you need. You get the exact amount you need. No waste. To determine how much you need measure the distance around your cab opening. It is important that both openings are exactly the same size. The average full-size pickup truck rear window opening is approximately 13 - 14 feet around. The average mini-truck is approximately 10 feet around the window opening.
- Is there a certain glue that can be used in conjunction with the accordion boot?
The rubber boot does not require glue for installation. This is because there is a spring clip embedded it the rubber. When the boot is placed over a flange the spring clip squeezes the rubber securely. The only place you may want to glue the boot is where it meets. This is however optional. To glue the seam where the two ends meet, you can use cyanoacrylate (i.e. SuperGlue). Do not use any petroleum based glues as it will react negatively to the rubber. (i.e. rubber cement). See Installing Accordion Boot for more details.
- Can you make the accordion gasket in different colors?
Sorry the boot only comes in black. We have never tested it, but the rubber is epdm and with the right paint is can be colored. From the research the recommended paint should be an acrylic coating specifically designed for epdm rubber. Usually this is paint for roofing. Latex paint should be avoided.
