Truck Cap Accordian Gasket
How to Choose the Right Rubber Boot Seal
You can purchase rubber boot material for your special project. This seal is manufactured from durable EPDM synthetic rubber substance and has a bendable spring steel clip for fastening to any flange. This material is available by the foot. To find how much you require measure the distance encircling your cab opening. You get three options of rubber to apply for sealing your cabs together.
Quick and Easy Installation
Installing this rubber boot is user-friendly and requires minimal tools. Just secure the seal firmly onto the frame of the window or pass through opening. This provides a weatherproof connection between the two units. Whether you're traveling, this seal blocks dust and maintains a dry space during your journey.
Universal Fit: Compatible Rubber Seals for Trucks and Rigs
This rubber boot seal is typically used in vehicle sealing applications. It's fits most full-size trucks. Whether you're retrofitting a camper shell or building a custom rig, this seal offers versatile fitment and dependable performance for your cab connection project.
Truck Cap Accordian Gasket Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Powder-Coated Friendly Channel | Seals well even on painted or coated surfaces | Ensures compatibility with modified or custom trucks |
| Flexible Bellows Design | Absorbs vibration and road movement without cracking | Great for off-road and long-haul driving |
| Adapts to Slightly Uneven Openings | Flexible enough to seal even when openings aren’t perfectly aligned | Even though it is best that the opening match exactly there is some wiggle room to make minor adjustments for custom truck and canopy installations |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Can I cut the truck cap accordian gasket to fit around a third brake light?
No, cutting is not recommended. Instead, remove the brake light and cover the hole, or change how the boot is mounted if you need to preserve the light.
- How do I measure for an accordion boot?
Use a flexible measuring tape to trace the perimeter of the pass-through opening between your cab and camper.
- How durable is the accordian rubber
This product is durable. For specific technical data on the rubber visit this page http://www.accordionboot.com/epdm-rubber-boot.php
