Truck Cap Window Boot
How to Choose the Right Rubber Boot Seal
You can obtain rubber boot material for your special project. This seal is extruded from resilient EPDM synthetic rubber compound and incorporates a pliable spring steel clip for attaching to any rim. This material is sold by the foot. To determine how much you need measure the distance around your cab opening. You get 3 options of rubber to use for sealing your cabs together.
Tips for Getting the Right Fit
To find how much you need measure the length around your cab opening. It is important that both openings are exactly the matching size. Make sure to measure the opening before ordering. Every installation is different.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is engineered to endure severe conditions such as sunlight. It's perfect for both weekend getaways. Compared to low-grade seals, this material offers more protection. It's a smart investment for anyone looking to preserve their truck cab connection with a dependable sealing solution.
Truck Cap Window Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Supports Walk-Through Conversions | Lets you convert separate spaces into one continuous interior | Used in van builds, campers, and custom sleeper cabs |
| Silicone-Friendly Seam Sealing | Easy to seal end joints with a small bead of silicone | Ensures total waterproofing where ends come together |
| Cleanable Surface | Easy to wipe down or blow clean for reinstallation | Using mild soap and water for cleaning maintenance |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- How is the accordion boot installed?
The boot slips into the opening between the truck cab and camper. Use clamps or sealant for a tight, weatherproof connection.
- How much will I need?
This material is sold by the foot. Unlike other companies that force you to buy more than you need. You get the exact amount you need. No waste. To determine how much you need measure the distance around your cab opening. It is important that both openings are exactly the same size. The average full-size pickup truck rear window opening is approximately 13 - 14 feet around. The average mini-truck is approximately 10 feet around the window opening.
- How thick is the accordion boot rubber?
The thickness of the rubber it is about 3/32" thick. (2.38mm).
