Camper Window Boot Gasket
How to Choose the Right Rubber Boot Seal
You can purchase rubber boot material for your special project. This seal is manufactured from tough EPDM synthetic rubber substance and uses a pliable spring steel clip for attaching to any flange. This material is available by the foot. To decide how much you need measure the distance around your cab opening. You have three alternatives of rubber to employ for waterproofing your cabs together.
Tips for Getting the Right Fit
To ascertain how much you require measure the distance around your cab opening. It is important that both openings are accurately the same size. Make sure to measure the opening before ordering. Every installation is different.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is critical for your vehicle project. This rubber boot stands out due to its premium construction and customer-approved reliability. We take pride on providing products that meet your demands for long-term performance. Don't settle for low-end seals, upgrade to one that's made for the road.
Camper Window Boot Gasket Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| EPDM Sponge Rubber Construction | Flexible, resilient seal that withstands weather and aging | Ideal for trucks, RVs, and sleeper cabs exposed to elements |
| U-Channel Orientation Consistency | Both U-shaped edges face the same way for easier installation | Helps avoid confusion during install, especially for beginners |
| Cleanable Surface | Easy to wipe down or blow clean for reinstallation | Using mild soap and water for cleaning maintenance |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- What is the purpose of a camper window boot gasket?
A camper window boot gasketprovides a sealed, flexible connection between the cab and camper shell, allowing access and preventing leaks, dust, and wind from entering.
- I am wondering if the compression boot can be trimmed to fit around the third brake light?
You cannot cut the boot to fit around the 3rd brake light. Here are a couple of things you may want to do.
- Remove the brake light and cover the opening with a thin plate.
- Instead of installing the boot to the shell, install the boot into the truck window opening. Do this only if you remove the rear window.
- I am getting a camper shell with a sliding glass window so I am taking the window out of my pickup and it looks like the Compression Boot would be what i need, I am wondering which is the best to get the Compression Boot - Part Number 540 or the Compression Bulb Seal - Part Number 545?
Both boot function the same. We carry both types as different cap manufacturers will use one or the other. But there are slight differences between the two styles.
The flap seal 540 is a single layer of rubber that presses against the cab. In order to seal the edge is a single straight flat edge.
The bulb seal 545 is different in this way. It has a rounded edge. the rubber is double walled with an empty cavity. The material is slightly softer and will conform to the shape of the truck.
Both seal perform similarly. When it come to which one it is really a matter of preference.
