Truck Cap Epdm Seal
How to Choose the Right Rubber Boot Seal
You can get rubber boot material for your special project. This seal is manufactured from tough EPDM synthetic rubber compound and integrates a bendable spring steel clip for attaching to any rim. This material is sold by the foot. To determine how much you need measure the distance around your cab opening. You have three alternatives of rubber to make use of for sealing your cabs together.
Tips for Getting the Right Fit
To ascertain how much you require measure the space around your cab opening. It is essential that both openings are precisely the equal size. Make sure to measure the opening before ordering. Every installation is different.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is built to resist harsh conditions such as cold. It's perfect for both commercial fleets. Compared to low-grade seals, this material retains flexibility. It's a smart investment for anyone looking to protect their truck cab connection with a dependable sealing solution.
Truck Cap Epdm Seal Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Cleanable Surface | Easy to wipe down or blow clean for reinstallation | Using mild soap and water for cleaning maintenance |
| Adapts to Slightly Uneven Openings | Flexible enough to seal even when openings aren’t perfectly aligned | Even though it is best that the opening match exactly there is some wiggle room to make minor adjustments for custom truck and canopy installations |
| Embedded Steel Spring Clip | Maintains a secure grip on flanges without adhesive | Stable connection between cab and shell |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Does the truck cap epdm sealrequire glue to install?
No glue is required. The truck cap epdm seal has a spring clip embedded in the EPDM rubber that clamps onto a thin flange. You can optionally glue the seam using cyanoacrylate (SuperGlue), but avoid petroleum-based adhesives.
- I`m about to put a a fiberglass shell on the back of my truck and I`m taking out the back window. I think the fiberglass shell opening is a bigger than the the back window of the truck. will the Accordion Boot or Compression Boot Gasket Material work?
In order for the accordion boot to work in your application both opening must be the exact size. If the opening in the fiberglass shell is smaller you have the option of resizing the opening to fit your rear window opening. If the opening in the fiberglass shell is bigger than the opening in your truck's window opening you are limited to using the compression boot.
- Do you carry the product in stock?
Yes, we try to keep inventory available so we can send your order a quickly as possible. However there are times, due to high order volume, stock can be depleted. If this is the case your items will be backorder and sent as soon as new inventory arrives.
