Bottom Rubber Seal Camper Shell
Only Buy What You Need - Rubber Boot Material Sold by the Foot
This item is purchased by the foot. Unlike other businesses that require you to buy more than you need. You acquire the proper amount you need. No overage.
Quick and Easy Installation
Installing this rubber boot is straightforward and can be done with few tools. Just fit the seal firmly onto the edge of the window or pass through opening. This creates a watertight connection between the two units. Regardless of whether you're hauling, this seal prevents wind and maintains a dry space during your journey.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is designed to endure extreme conditions such as sunlight. It's ideal for both weekend getaways. Compared to cheaper seals, this material performs better. It's a reliable option for anyone looking to enhance their truck cab connection with a dependable sealing solution.
Bottom Rubber Seal Camper Shell Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Compressed and Expanded Flex | Adapts to body movement and misalignments | Maintains seal during travel, loading, or frame shifts |
| Custom Length | Get the exact amount you need with no waste or shortages | Great for DIY box truck or custom overland builds |
| Cleanable Surface | Easy to wipe down or blow clean for reinstallation | Using mild soap and water for cleaning maintenance |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Will the bottom rubber seal camper shell work with thin metal or wood frames?
Yes, but there must be a flange no thicker than 3/16". For wood or thick materials, add a metal strip (like aluminum flat bar) around the opening for the bottom rubber seal camper shellto grip.
- I am installing a boot between a truck cab and utility box.The box is about 1/2" thick. Will the boot clips expand over that type of material?
The material will not stretch that far. The maximum size that flange can be is 3/16" to receive the rubber. One solution to consider is to use flat bar and attach that around the opening in the box. One thing you must also remember - both opening need to be the same size and similar in shape.
- I have a Ford F150 with a LEER top. I an pretty sure the accordion seal is the correct option but the warning that the opening must be an exact match has me concerned. It looks like the truck opening is larger at the lower corners but until the window is removed, who knows? Am I on safe ground getting the accordion seal for this application?
The accordion boot only stretches one direction. There is a metal clip embedded in the rubber that allow you to attach the boot to the fiberglass/sheet metal, Therefore both window openings must be the same size. If the opening in the shell is smaller you can cut and trim the fiberglass to match the truck's window opening.
