Acordian Boot Truck
How to Choose the Right Rubber Boot Seal
You can purchase rubber boot material for your special project. This seal is manufactured from resilient EPDM synthetic rubber substance and contains a pliable spring steel clip for fastening to any rim. This material is available by the foot. To decide how much you need measure the distance encircling your cab opening. You get three choices of rubber to apply for sealing your cabs together.
Quick and Easy Installation
Installing this rubber boot is user-friendly and requires minimal tools. Just secure the seal tightly onto the edge of the window or pass through opening. This forms a weatherproof connection between the two units. Whether you're adventuring, this seal keeps out debris and maintains cabin integrity during your journey.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is important for your vehicle project. This rubber boot delivers due to its premium construction and real-world reliability. We focus on providing products that exceed your expectations for long-term performance. Don't settle for cheap seals, upgrade to one that's made for the road.
Acordian Boot Truck Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Proven on Sleeper Cab Trucks | Successfully used between cab and sleeper on heavy-duty trucks | Ideal for semi trucks |
| Fast, Reliable Shipping | Quick turnaround when time-sensitive installs are needed | Helpful for last-minute road trip or show prep |
| EPDM Sponge Rubber Construction | Flexible, resilient seal that withstands weather and aging | Ideal for trucks, RVs, and sleeper cabs exposed to elements |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- How do I cancel an order?
If you need to cancel your order, simply contact Customer Service. Please include the invoice number of the item that you would like to cancel to ensure accuracy. Once the product is shipped there will be a 10% restocking fee.
- I am installing a boot between a truck cab and utility box.The box is about 1/2" thick. Will the boot clips expand over that type of material?
The material will not stretch that far. The maximum size that flange can be is 3/16" to receive the rubber. One solution to consider is to use flat bar and attach that around the opening in the box. One thing you must also remember - both opening need to be the same size and similar in shape.
- Can you make the accordion gasket in different colors?
Sorry the boot only comes in black. We have never tested it, but the rubber is epdm and with the right paint is can be colored. From the research the recommended paint should be an acrylic coating specifically designed for epdm rubber. Usually this is paint for roofing. Latex paint should be avoided.
