Truck Bed Camper Gasket
How to Choose the Right Rubber Boot Seal
You can get rubber boot material for your special project. This seal is extruded from long-lasting EPDM synthetic rubber compound and incorporates a flexible spring steel clip for affixing to any flange. This material is available by the foot. To find how much you need measure the length around your cab opening. You have three choices of rubber to employ for waterproofing your cabs together.
Tips for Getting the Right Fit
To determine how much you want measure the space around your cab opening. It is essential that both openings are accurately the matching size. Make sure to measure the opening before ordering. Every installation is different.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is built to withstand severe conditions such as sunlight. It's perfect for both off-grid builds. Compared to low-grade seals, this material lasts longer. It's a solid choice for anyone looking to protect their truck cab connection with a dependable sealing solution.
Truck Bed Camper Gasket Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Trusted by Pros and DIYers | Field-tested by thousands in real-world applications | Confidence in product from verified reviews and installs |
| Cleanable Surface | Easy to wipe down or blow clean for reinstallation | Using mild soap and water for cleaning maintenance |
| Affordable, High-Value Solution | Great quality at a competitive price point | Cost-effective choice for budget-conscious builders |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Can I keep my sliding windows and still use a truck bed camper gasket?
Unfortunately, no. The slider windows must be removed because the truck bed camper gasket requires a clean flange or wall to attach. Sliders block access to this area.
- Can I get samples of the boot?
Yes, we offer a sample pack that includes each of the boot styles. Getting a sample will help you know and understand how the boot installs and attaches to your vehicle or special project. To order a sample pack go to Boot Sample
- I have a Ford F150 with a LEER top. I an pretty sure the accordion seal is the correct option but the warning that the opening must be an exact match has me concerned. It looks like the truck opening is larger at the lower corners but until the window is removed, who knows? Am I on safe ground getting the accordion seal for this application?
The accordion boot only stretches one direction. There is a metal clip embedded in the rubber that allow you to attach the boot to the fiberglass/sheet metal, Therefore both window openings must be the same size. If the opening in the shell is smaller you can cut and trim the fiberglass to match the truck's window opening.
