Camper Gasket Boot
How to Choose the Right Rubber Boot Seal
You can purchase rubber boot material for your special project. This seal is extruded from resilient EPDM synthetic rubber substance and contains a bendable spring steel clip for attaching to any rim. This material is available by the foot. To decide how much you require measure the length around your cab opening. You have three alternatives of rubber to apply for sealing your cabs together.
Quick and Easy Installation
Installing this rubber boot is straightforward and requires minimal tools. Just press the seal firmly onto the frame of the window or pass through opening. This provides a watertight connection between the two units. Regardless of whether you're traveling, this seal keeps out moisture and preserves a dry space during your journey.
Universal Fit: Compatible Rubber Seals for Trucks and Rigs
This rubber boot seal is often used in truck modifications. It's works with most mid-size trucks. Whether you're repairing a camper shell or building a bespoke rig, this seal offers versatile fitment and dependable performance for your cab connection project.
Camper Gasket Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Prevents Heat and Sound Transfer | Improves cab comfort by blocking wind and road noise | Useful for sleepers and audio builds |
| Proven on Sleeper Cab Trucks | Successfully used between cab and sleeper on heavy-duty trucks | Ideal for semi trucks |
| U-Channel Orientation Consistency | Both U-shaped edges face the same way for easier installation | Helps avoid confusion during install, especially for beginners |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Can I install a camper gasket boot in cold weather?
Yes, but it's best to warm the camper gasket boot slightly beforehand. Cold temperatures may make the rubber less flexible and harder to manipulate during installation.
- What’s the difference between the flap and bulb compression boot?
The flap version has a straight edge, while the bulb version includes a rounded, softer cushion for enhanced sealing and flexibility.
- I`m about to put a a fiberglass shell on the back of my truck and I`m taking out the back window. I think the fiberglass shell opening is a bigger than the the back window of the truck. will the Accordion Boot or Compression Boot Gasket Material work?
In order for the accordion boot to work in your application both opening must be the exact size. If the opening in the fiberglass shell is smaller you have the option of resizing the opening to fit your rear window opening. If the opening in the fiberglass shell is bigger than the opening in your truck's window opening you are limited to using the compression boot.
