Window Truck Shell Gasket
How to Choose the Right Rubber Boot Seal
You can get rubber boot material for your special project. This seal is manufactured from resilient EPDM synthetic rubber compound and incorporates a pliable spring steel clip for attaching to any rim. This material is available by the foot. To specify how much you need measure the length around your cab opening. You have 3 options of rubber to use for sealing your cabs together.
Quick and Easy Installation
Installing this rubber boot is hassle-free and requires minimal tools. Just fit the seal firmly onto the frame of the window or pass through opening. This forms a secure connection between the two units. Whether you're traveling, this seal prevents wind and preserves interior comfort during your journey.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is crucial for your vehicle project. This rubber boot excels due to its high-quality construction and customer-approved reliability. We take pride on providing products that exceed your demands for long-term durability. Don't settle for flimsy seals, upgrade to one that's made for the road.
Window Truck Shell Gasket Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Fast, Reliable Shipping | Quick turnaround when time-sensitive installs are needed | Helpful for last-minute road trip or show prep |
| Urethane Adhesive Compatible | Allows permanent seal when needed for high-stress areas | Used in high-vibration or heavy-use applications |
| Weather-Tested Seal | Handles rainstorms without leaks or performance loss | Reliable weather barrier for daily-use trucks or RVs |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Does the window truck shell gasket require glue to install?
No glue is required. The window truck shell gasket has a spring clip embedded in the EPDM rubber that clamps onto a thin flange. You can optionally glue the seam using cyanoacrylate (SuperGlue), but avoid petroleum-based adhesives.
- I am installing a boot between a truck cab and utility box.The box is about 1/2" thick. Will the boot clips expand over that type of material?
The material will not stretch that far. The maximum size that flange can be is 3/16" to receive the rubber. One solution to consider is to use flat bar and attach that around the opening in the box. One thing you must also remember - both opening need to be the same size and similar in shape.
- Will one of these work on both sliding windows on truck & cap? I don't want to remove either sliding window.
In order for the boot to attach to the vehicle there must be some sort of thin wall or flange. Keeping the slider window will cover any flange or thin wall. In short you will not be able to use any or the boots if you keep the sliding windows in place as there will be no mechanical method to install the boot.
