Window Boot For Camper
How to Choose the Right Rubber Boot Seal
You can acquire rubber boot material for your special project. This seal is extruded from durable EPDM synthetic rubber compound and uses a pliable spring steel clip for attaching to any flange. This material is available by the foot. To decide how much you need measure the distance encircling your cab opening. You get several options of rubber to make use of for waterproofing your cabs together.
Quick and Easy Installation
Installing this rubber boot is straightforward and can be done with few tools. Just press the seal firmly onto the thin wall of the window or pass through opening. This ensures a weatherproof connection between the two units. Regardless of whether you're camping, this seal blocks dust and helps a dry space during your journey.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is crafted to resist extreme conditions such as UV exposure. It's perfect for both long-term installations. Compared to low-grade seals, this material offers more protection. It's a smart investment for anyone looking to enhance their truck cab connection with a dependable sealing solution.
Window Boot For Camper Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Embedded Steel Spring Clip | Maintains a secure grip on flanges without adhesive | Stable connection between cab and shell |
| Custom Length | Get the exact amount you need with no waste or shortages | Great for DIY box truck or custom overland builds |
| Urethane Adhesive Compatible | Allows permanent seal when needed for high-stress areas | Used in high-vibration or heavy-use applications |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Can I custom trim a window boot for camper to fit my setup?
You can trim the length to fit your application, but altering the shape, corners, or embedded clip area is not recommended.
- Is it suitable for sealing between an airbag mounted truck cab and the body hard mounted to chassis rails on a truck?
As long as there is some sort of flange or wall to install the boot it should work. The thickness of the flange should not exceed 3/16" (4.7625mm) The accordion design allows for independent movement or flex between the cab bodies.
- Can you make the accordion gasket in different colors?
Sorry the boot only comes in black. We have never tested it, but the rubber is epdm and with the right paint is can be colored. From the research the recommended paint should be an acrylic coating specifically designed for epdm rubber. Usually this is paint for roofing. Latex paint should be avoided.
