Truck Window Boot Seal
How to Choose the Right Rubber Boot Seal
You can get rubber boot material for your special project. This seal is manufactured from robust EPDM synthetic rubber substance and has a pliable spring steel clip for fastening to any flange. This material is sold by the foot. To ascertain how much you require measure the distance around your cab opening. You get several choices of rubber to employ for waterproofing your cabs together.
Quick and Easy Installation
Installing this rubber boot is user-friendly and can be done with few tools. Just press the seal firmly onto the rim of the window or pass through opening. This provides a secure connection between the two units. Regardless of whether you're traveling, this seal keeps out rain and helps interior comfort during your journey.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is designed to handle extreme conditions such as cold. It's perfect for both commercial fleets. Compared to standard seals, this material offers more protection. It's a solid choice for anyone looking to enhance their truck cab connection with a dependable sealing solution.
Truck Window Boot Seal Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Powder-Coated Friendly Channel | Seals well even on painted or coated surfaces | Ensures compatibility with modified or custom trucks |
| Flexible Bellows Design | Absorbs vibration and road movement without cracking | Great for off-road and long-haul driving |
| UV & Weather Resistant | Withstands sun, rain, and temperature changes without cracking | Long-term durability for vehicles stored outdoors |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Does the truck window boot seal require glue to install?
No glue is required. The truck window boot seal has a spring clip embedded in the EPDM rubber that clamps onto a thin flange. You can optionally glue the seam using cyanoacrylate (SuperGlue), but avoid petroleum-based adhesives.
- What if the camper shell opening is larger than my truck window?
If the shell opening is larger, the truck window boot seal may not work. You’ll either need to modify the opening or consider a compression boot instead, which is more forgiving in such situations.
- I am getting a camper shell with a sliding glass window so I am taking the window out of my pickup and it looks like the Compression Boot would be what i need, I am wondering which is the best to get the Compression Boot - Part Number 540 or the Compression Bulb Seal - Part Number 545?
Both boot function the same. We carry both types as different cap manufacturers will use one or the other. But there are slight differences between the two styles.
The flap seal 540 is a single layer of rubber that presses against the cab. In order to seal the edge is a single straight flat edge.
The bulb seal 545 is different in this way. It has a rounded edge. the rubber is double walled with an empty cavity. The material is slightly softer and will conform to the shape of the truck.
Both seal perform similarly. When it come to which one it is really a matter of preference.
