Truck To Cap Accordian Gasket
How to Choose the Right Rubber Boot Seal
You can get rubber boot material for your special project. This seal is extruded from hard-wearing EPDM synthetic rubber substance and incorporates a pliable spring steel clip for affixing to any flange. This material is available by the foot. To specify how much you require measure the distance encircling your cab opening. You have several alternatives of rubber to make use of for sealing your cabs together.
Tips for Getting the Right Fit
To ascertain how much you need measure the space around your cab opening. It is essential that both openings are exactly the same size. Make sure to measure the opening before ordering. Every installation is different.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is crucial for your vehicle project. This rubber boot delivers due to its superior construction and customer-approved reliability. We pride ourselves on providing products that meet your needs for long-term satisfaction. Don't settle for cheap seals, upgrade to one that's built to last.
Truck To Cap Accordian Gasket Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Urethane Adhesive Compatible | Allows permanent seal when needed for high-stress areas | Used in high-vibration or heavy-use applications |
| Proven on Sleeper Cab Trucks | Successfully used between cab and sleeper on heavy-duty trucks | Ideal for semi trucks |
| EPDM Sponge Rubber Construction | Flexible, resilient seal that withstands weather and aging | Ideal for trucks, RVs, and sleeper cabs exposed to elements |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Can I install the truck to cap accordian gasket by myself?
Most users successfully install the truck to cap accordian gasket with basic tools, soap solution, and occasionally a helper for positioning.
- How is the accordion boot installed?
The boot slips into the opening between the truck cab and camper. Use clamps or sealant for a tight, weatherproof connection.
- Can you make the accordion gasket in different colors?
Sorry the boot only comes in black. We have never tested it, but the rubber is epdm and with the right paint is can be colored. From the research the recommended paint should be an acrylic coating specifically designed for epdm rubber. Usually this is paint for roofing. Latex paint should be avoided.
