Truck Shell Seals
How to Choose the Right Rubber Boot Seal
You can get rubber boot material for your special project. This seal is manufactured from hard-wearing EPDM synthetic rubber substance and uses a pliable spring steel clip for attaching to any rim. This material is sold by the foot. To find how much you need measure the distance encircling your cab opening. You get three options of rubber to make use of for sealing your cabs together.
Quick and Easy Installation
Installing this rubber boot is hassle-free and can be done with few tools. Just clip the seal firmly onto the thin wall of the window or pass through opening. This creates a watertight connection between the two units. Regardless of whether you're adventuring, this seal keeps out moisture and maintains a dry space during your journey.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is important for your vehicle project. This rubber boot delivers due to its high-quality construction and real-world reliability. We focus on providing products that meet your needs for long-term performance. Don't settle for inferior seals, upgrade to one that's built to last.
Truck Shell Seals Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Powder-Coated Friendly Channel | Seals well even on painted or coated surfaces | Ensures compatibility with modified or custom trucks |
| Prevents Heat and Sound Transfer | Improves cab comfort by blocking wind and road noise | Useful for sleepers and audio builds |
| Weather-Tested Seal | Handles rainstorms without leaks or performance loss | Reliable weather barrier for daily-use trucks or RVs |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Does the truck shell sealsrequire glue to install?
No glue is required. The truck shell seals has a spring clip embedded in the EPDM rubber that clamps onto a thin flange. You can optionally glue the seam using cyanoacrylate (SuperGlue), but avoid petroleum-based adhesives.
- I have a fiber glass camper shell. I want access to my camper shell from inside my cab but I don't want to lose heat and have a weatherproof seal. Will this product provide the right solution?
The accordion boot creates an air-tight and weather tight seal between the cabs. It does not provide any insulation. However, heat loss in minimize by the air-tight seal.
- How thick is the accordion boot rubber?
The thickness of the rubber it is about 3/32" thick. (2.38mm).
