Truck Boot Accordion
How to Choose the Right Rubber Boot Seal
You can purchase rubber boot material for your special project. This seal is manufactured from durable EPDM synthetic rubber compound and integrates a flexible spring steel clip for attaching to any rim. This material is sold by the foot. To specify how much you require measure the distance encircling your cab opening. You have three choices of rubber to employ for waterproofing your cabs together.
Quick and Easy Installation
Installing this rubber boot is hassle-free and requires minimal tools. Just fit the seal firmly onto the rim of the window or pass through opening. This forms a tight connection between the two units. Regardless of whether you're adventuring, this seal keeps out debris and maintains cabin integrity during your journey.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is designed to endure extreme conditions such as heat. It's suitable for both commercial fleets. Compared to standard seals, this material performs better. It's a solid choice for anyone looking to preserve their truck cab connection with a dependable sealing solution.
Truck Boot Accordion Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| No Sealant Required | Cleaner installation with easy removal if needed | Perfect for quick and easy installs |
| Proven on Sleeper Cab Trucks | Successfully used between cab and sleeper on heavy-duty trucks | Ideal for semi trucks |
| Made in the USA | High manufacturing standards and local support | Ideal for buyers who value American-made products |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- How do I know if I need a truck boot accordion or a compression boot?
Use a truck boot accordionwhen both openings are identical in size and shape. Use a compression boot if there are size differences or no solid flange available.
- Can I custom trim a truck boot accordion to fit my setup?
You can trim the length to fit your application, but altering the shape, corners, or embedded clip area is not recommended.
- I am installing a boot between a truck cab and utility box.The box is about 1/2" thick. Will the boot clips expand over that type of material?
The material will not stretch that far. The maximum size that flange can be is 3/16" to receive the rubber. One solution to consider is to use flat bar and attach that around the opening in the box. One thing you must also remember - both opening need to be the same size and similar in shape.
