Truck And Camper Shell Boot
How to Choose the Right Rubber Boot Seal
You can obtain rubber boot material for your special project. This seal is extruded from heavy-duty EPDM synthetic rubber substance and contains a pliable spring steel clip for affixing to any flange. This material is sold by the foot. To determine how much you need measure the distance encircling your cab opening. You get three alternatives of rubber to apply for waterproofing your cabs together.
Tips for Getting the Right Fit
To specify how much you need measure the distance around your cab opening. It is important that both openings are precisely the matching size. Make sure to measure the opening before ordering. Every installation is unique.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is engineered to resist challenging conditions such as cold. It's perfect for both off-grid builds. Compared to cheaper seals, this material performs better. It's a reliable option for anyone looking to protect their truck cab connection with a dependable sealing solution.
Truck And Camper Shell Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Weather-Tested Seal | Handles rainstorms without leaks or performance loss | Reliable weather barrier for daily-use trucks or RVs |
| Proven on Sleeper Cab Trucks | Successfully used between cab and sleeper on heavy-duty trucks | Ideal for semi trucks |
| UV & Weather Resistant | Withstands sun, rain, and temperature changes without cracking | Long-term durability for vehicles stored outdoors |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Will the truck and camper shell boot work with thin metal or wood frames?
Yes, but there must be a flange no thicker than 3/16". For wood or thick materials, add a metal strip (like aluminum flat bar) around the opening for the truck and camper shell bootto grip.
- How long will my truck and camper shell boot last?
EPDM rubber is extremely durable, UV-resistant, and built to last for years. Proper installation can extend its lifespan significantly.
- What tools do I need to install atruck and camper shell boot?
Basic tools like a utility knife, heavy duty siccors, measuring tape, a soft mallet, are usually sufficient for installing a truck and camper shell boot.
