Camper Shell Boot Collar
How to Choose the Right Rubber Boot Seal
You can obtain rubber boot material for your special project. This seal is manufactured from resilient EPDM synthetic rubber substance and integrates a flexible spring steel clip for fastening to any rim. This material is sold by the foot. To specify how much you require measure the distance around your cab opening. You have several choices of rubber to make use of for sealing your cabs together.
Tips for Getting the Right Fit
To find how much you want measure the space around your cab opening. It is vital that both openings are perfectly the equal size. Make sure to measure the opening before ordering. Every installation is unique.
Universal Fit: Compatible Rubber Seals for Trucks and Rigs
This rubber boot seal is often used in vehicle sealing applications. It's compatible with most compact trucks. Whether you're retrofitting a camper shell or building a personalized rig, this seal offers universal fitment and dependable performance for your cab connection project.
Camper Shell Boot Collar Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Forgiving Fit | Can accommodate minor mismatches in height and width | Useful for older vehicles or hand-cut openings |
| Silicone-Friendly Seam Sealing | Easy to seal end joints with a small bead of silicone | Ensures total waterproofing where ends come together |
| Weather-Tested Seal | Handles rainstorms without leaks or performance loss | Reliable weather barrier for daily-use trucks or RVs |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Does the camper shell boot collar require glue to install?
No glue is required. The camper shell boot collar has a spring clip embedded in the EPDM rubber that clamps onto a thin flange. You can optionally glue the seam using cyanoacrylate (SuperGlue), but avoid petroleum-based adhesives.
- What if I don't like something?
Your complete satisfaction is very important to us! We guarantee that if you do not like your merchandise, or it is broken, you can return it and get your money back. This 100% satisfaction money-back guarantee is good for 30 days.
- I am making a walk through conversion on my pickup truck to allow access in the bed. I want to to cut the wall between the cab and bed to make one continuous passenger cabin to the camper shell. I also want something that looks decent, and will last. Will the accordion boot work in this situation?
Yes, the accordion boot will work for you in this type of installation. For more details on how to create and seal a cut through go to the Cut Through FAQ page for more details
