Sealing Camper Shell Boots
How to Choose the Right Rubber Boot Seal
You can buy rubber boot material for your special project. This seal is extruded from tough EPDM synthetic rubber compound and uses a flexible spring steel clip for attaching to any flange. This material is sold by the foot. To specify how much you require measure the distance around your cab opening. You have several alternatives of rubber to employ for sealing your cabs together.
Quick and Easy Installation
Installing this rubber boot is user-friendly and can be done with few tools. Just fit the seal firmly onto the frame of the window or pass through opening. This forms a secure connection between the two units. Regardless of whether you're hauling, this seal keeps out wind and preserves a dry space during your journey.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is essential for your vehicle project. This rubber boot delivers due to its superior construction and real-world reliability. We take pride on providing products that surpass your demands for long-term durability. Don't settle for cheap seals, upgrade to one that's engineered for adventure.
Sealing Camper Shell Boots Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Affordable, High-Value Solution | Great quality at a competitive price point | Cost-effective choice for budget-conscious builders |
| Reusable with Careful Removal | Can be reinstalled without damage if no adhesive used | Ideal for resprays, upgrades, or camper swaps |
| Embedded Steel Spring Clip | Maintains a secure grip on flanges without adhesive | Stable connection between cab and shell |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- How long does it take to receive my sealing camper shell boots rder?
Delivery typically takes 3 to 10 days depending on your location and order volume.
- Is professional installation recommended for a sealing camper shell boots?
Most DIYers can install it successfully, but if you're unsure or working with custom cuts, a professional installer may help ensure a perfect fit.
- I am making a walk through conversion on my pickup truck to allow access in the bed. I want to to cut the wall between the cab and bed to make one continuous passenger cabin to the camper shell. I also want something that looks decent, and will last. Will the accordion boot work in this situation?
Yes, the accordion boot will work for you in this type of installation. For more details on how to create and seal a cut through go to the Cut Through FAQ page for more details
