Seal Between Camper Shell And Cab Of Truck
How to Choose the Right Rubber Boot Seal
You can buy rubber boot material for your special project. This seal is manufactured from long-lasting EPDM synthetic rubber compound and has a bendable spring steel clip for attaching to any flange. This material is sold by the foot. To determine how much you need measure the length encircling your cab opening. You get several choices of rubber to make use of for sealing your cabs together.
Tips for Getting the Right Fit
To ascertain how much you require measure the space around your cab opening. It is important that both openings are accurately the same size. Make sure to measure the opening before ordering. Every installation is different.
Universal Fit: Compatible Rubber Seals for Trucks and Rigs
This rubber boot seal is frequently used in truck modifications. It's works with most standard trucks. Whether you're retrofitting a camper shell or building a custom rig, this seal offers broad fitment and dependable performance for your cab connection project.
Seal Between Camper Shell And Cab Of Truck Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Compressed and Expanded Flex | Adapts to body movement and misalignments | Maintains seal during travel, loading, or frame shifts |
| Adapts to Slightly Uneven Openings | Flexible enough to seal even when openings aren’t perfectly aligned | Even though it is best that the opening match exactly there is some wiggle room to make minor adjustments for custom truck and canopy installations |
| Urethane Adhesive Compatible | Allows permanent seal when needed for high-stress areas | Used in high-vibration or heavy-use applications |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Can I cut the seal between camper shell and cab of truck to fit around a third brake light?
No, cutting is not recommended. Instead, remove the brake light and cover the hole, or change how the boot is mounted if you need to preserve the light.
- What do you charge for shipping?
Here are the various charges for shipping both Domestic and International
Part 540 Compression Boot - Flap $19.98 Part 541 Accordion Boot $19.98 Part 543 Wide Accordion Boot $27.76 Part 544 Extra Wide Accordion Boot $27.76 Part 545 Compression boot - Bulb $19.98 Canada $76.95 International $110.00 - I am getting a camper shell with a sliding glass window so I am taking the window out of my pickup and it looks like the Compression Boot would be what i need, I am wondering which is the best to get the Compression Boot - Part Number 540 or the Compression Bulb Seal - Part Number 545?
Both boot function the same. We carry both types as different cap manufacturers will use one or the other. But there are slight differences between the two styles.
The flap seal 540 is a single layer of rubber that presses against the cab. In order to seal the edge is a single straight flat edge.
The bulb seal 545 is different in this way. It has a rounded edge. the rubber is double walled with an empty cavity. The material is slightly softer and will conform to the shape of the truck.
Both seal perform similarly. When it come to which one it is really a matter of preference.
