Rubber Boot For Camper Shell
How to Choose the Right Rubber Boot Seal
You can get rubber boot material for your special project. This seal is extruded from hard-wearing EPDM synthetic rubber compound and uses a bendable spring steel clip for fastening to any flange. This material is available by the foot. To decide how much you need measure the distance encircling your cab opening. You get several options of rubber to apply for sealing your cabs together.
Quick and Easy Installation
Installing this rubber boot is straightforward and can be done with few tools. Just press the seal tightly onto the thin wall of the window or pass through opening. This provides a secure connection between the two units. Even if you're off-roading, this seal prevents wind and maintains a dry space during your journey.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is engineered to resist extreme conditions such as UV exposure. It's tailored for both commercial fleets. Compared to low-grade seals, this material retains flexibility. It's a solid choice for anyone looking to upgrade their truck cab connection with a dependable sealing solution.
Rubber Boot For Camper Shell Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Adapts to Slightly Uneven Openings | Flexible enough to seal even when openings aren’t perfectly aligned | Even though it is best that the opening match exactly there is some wiggle room to make minor adjustments for custom truck and canopy installations |
| EPDM Sponge Rubber Construction | Flexible, resilient seal that withstands weather and aging | Ideal for trucks, RVs, and sleeper cabs exposed to elements |
| Reusable with Careful Removal | Can be reinstalled without damage if no adhesive used | Ideal for resprays, upgrades, or camper swaps |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- How long will my rubber boot for camper shell last?
EPDM rubber is extremely durable, UV-resistant, and built to last for years. Proper installation can extend its lifespan significantly.
- How much will I need?
This material is sold by the foot. Unlike other companies that force you to buy more than you need. You get the exact amount you need. No waste. To determine how much you need measure the distance around your cab opening. It is important that both openings are exactly the same size. The average full-size pickup truck rear window opening is approximately 13 - 14 feet around. The average mini-truck is approximately 10 feet around the window opening.
- I have a fiber glass camper shell. I want access to my camper shell from inside my cab but I don't want to lose heat and have a weatherproof seal. Will this product provide the right solution?
The accordion boot creates an air-tight and weather tight seal between the cabs. It does not provide any insulation. However, heat loss in minimize by the air-tight seal.
