Sealing Boot For Slideout
How to Choose the Right Rubber Boot Seal
You can get rubber boot material for your special project. This seal is extruded from resilient EPDM synthetic rubber compound and integrates a pliable spring steel clip for attaching to any rim. This material is sold by the foot. To determine how much you need measure the length around your cab opening. You get three alternatives of rubber to make use of for waterproofing your cabs together.
Quick and Easy Installation
Installing this rubber boot is simple and requires minimal tools. Just attach the seal tightly onto the thin wall of the window or pass through opening. This forms a secure connection between the two units. Even if you're adventuring, this seal blocks dust and helps cabin integrity during your journey.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is critical for your vehicle project. This rubber boot stands out due to its industrial-strength construction and real-world reliability. We pride ourselves on providing products that surpass your demands for long-term durability. Don't settle for flimsy seals, upgrade to one that's built to last.
Sealing Boot For Slideout Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Compressed and Expanded Flex | Adapts to body movement and misalignments | Maintains seal during travel, loading, or frame shifts |
| Affordable, High-Value Solution | Great quality at a competitive price point | Cost-effective choice for budget-conscious builders |
| Embedded Steel Spring Clip | Maintains a secure grip on flanges without adhesive | Stable connection between cab and shell |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- What if the camper shell opening is larger than my truck window?
If the shell opening is larger, the sealing boot for slideout may not work. You’ll either need to modify the opening or consider a compression boot instead, which is more forgiving in such situations.
- Can I cut the sealing boot for slideout to fit around a third brake light?
No, cutting is not recommended. Instead, remove the brake light and cover the hole, or change how the boot is mounted if you need to preserve the light.
- I have a truck with a wood framed utility box and would like join the cab and box using the accordion boot. How to I attach the boot?
You will not be able to attach the boot material to the wood, It is too thick. The best way to remedy this is to add a flange to the box. This could be done with steel or aluminum flat bar, or something similar (i.e. sheet metal, fiberglass), installed around the perimeter of the opening to allow the boot to attach to the box
