Rear Window Pass Through Camper Shell
How to Choose the Right Rubber Boot Seal
You can obtain rubber boot material for your special project. This seal is extruded from resilient EPDM synthetic rubber compound and contains a pliable spring steel clip for affixing to any rim. This material is sold by the foot. To specify how much you require measure the length encircling your cab opening. You get three alternatives of rubber to make use of for waterproofing your cabs together.
Quick and Easy Installation
Installing this rubber boot is hassle-free and can be done with few tools. Just clip the seal firmly onto the thin wall of the window or pass through opening. This creates a secure connection between the two units. Even if you're camping, this seal keeps out rain and helps a dry space during your journey.
Universal Fit: Compatible Rubber Seals for Trucks and Rigs
This rubber boot seal is frequently used in vehicle sealing applications. It's fits most full-size trucks. Whether you're repairing a camper shell or building a personalized rig, this seal offers broad fitment and dependable performance for your cab connection project.
Rear Window Pass Through Camper Shell Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Powder-Coated Friendly Channel | Seals well even on painted or coated surfaces | Ensures compatibility with modified or custom trucks |
| Silicone-Friendly Seam Sealing | Easy to seal end joints with a small bead of silicone | Ensures total waterproofing where ends come together |
| Embedded Steel Spring Clip | Maintains a secure grip on flanges without adhesive | Stable connection between cab and shell |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- What is the minimum corner radius I can use?
The recommended minimum radius for corners is 1 inch. Tighter corners may cause the rear window pass through camper shell to bunch or kink.
- How long will my rear window pass through camper shell last?
EPDM rubber is extremely durable, UV-resistant, and built to last for years. Proper installation can extend its lifespan significantly.
- Can you make the accordion gasket in different colors?
Sorry the boot only comes in black. We have never tested it, but the rubber is epdm and with the right paint is can be colored. From the research the recommended paint should be an acrylic coating specifically designed for epdm rubber. Usually this is paint for roofing. Latex paint should be avoided.
