Truck Cab To Cap Weather Seal
How to Choose the Right Rubber Boot Seal
You can purchase rubber boot material for your special project. This seal is extruded from tough EPDM synthetic rubber substance and contains a bendable spring steel clip for attaching to any flange. This material is sold by the foot. To specify how much you need measure the distance around your cab opening. You have 3 options of rubber to use for sealing your cabs together.
Quick and Easy Installation
Installing this rubber boot is straightforward and can be done with few tools. Just clip the seal tightly onto the flange of the window or pass through opening. This forms a secure connection between the two units. Whether you're adventuring, this seal prevents rain and maintains a dry space during your journey.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is important for your vehicle project. This rubber boot stands out due to its premium construction and real-world reliability. We focus on providing products that exceed your needs for long-term performance. Don't settle for low-end seals, upgrade to one that's engineered for adventure.
Truck Cab To Cap Weather Seal Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Compressed and Expanded Flex | Adapts to body movement and misalignments | Maintains seal during travel, loading, or frame shifts |
| Made in the USA | High manufacturing standards and local support | Ideal for buyers who value American-made products |
| Silicone-Friendly Seam Sealing | Easy to seal end joints with a small bead of silicone | Ensures total waterproofing where ends come together |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Is the truck cab to cap weather seal reusable if I remove it?
While technically reusable, removal often deforms the material or compromises the embedded clip, so we recommend replacing it if removed.
- What do you charge for shipping?
Here are the various charges for shipping both Domestic and International
Part 540 Compression Boot - Flap $17.45 Part 541 Accordion Boot $17.45 Part 543 Wide Accordion Boot $24.35 Part 544 Extra Wide Accordion Boot $24.35 Part 545 Compression boot - Bulb $17.45 Canada $76.95 International $110.00 - I`m about to put a a fiberglass shell on the back of my truck and I`m taking out the back window. I think the fiberglass shell opening is a bigger than the the back window of the truck. will the Accordion Boot or Compression Boot Gasket Material work?
In order for the accordion boot to work in your application both opening must be the exact size. If the opening in the fiberglass shell is smaller you have the option of resizing the opening to fit your rear window opening. If the opening in the fiberglass shell is bigger than the opening in your truck's window opening you are limited to using the compression boot.
