Open Boot For Camper Shell
How to Choose the Right Rubber Boot Seal
You can obtain rubber boot material for your special project. This seal is extruded from durable EPDM synthetic rubber substance and contains a flexible spring steel clip for affixing to any rim. This material is available by the foot. To determine how much you need measure the distance around your cab opening. You have three options of rubber to employ for waterproofing your cabs together.
Quick and Easy Installation
Installing this rubber boot is easy and requires minimal tools. Just fit the seal tightly onto the rim of the window or pass through opening. This provides a secure connection between the two units. Even if you're hauling, this seal keeps out debris and helps cabin integrity during your journey.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is essential for your vehicle project. This rubber boot excels due to its premium construction and real-world reliability. We pride ourselves on providing products that exceed your demands for long-term value. Don't settle for cheap seals, upgrade to one that's made for the road.
Open Boot For Camper Shell Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Supports Walk-Through Conversions | Lets you convert separate spaces into one continuous interior | Used in van builds, campers, and custom sleeper cabs |
| UV & Weather Resistant | Withstands sun, rain, and temperature changes without cracking | Long-term durability for vehicles stored outdoors |
| Adapts to Slightly Uneven Openings | Flexible enough to seal even when openings aren’t perfectly aligned | Even though it is best that the opening match exactly there is some wiggle room to make minor adjustments for custom truck and canopy installations |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Will the open boot for camper shell work on a walk-through truck conversion?
Yes! This is a perfect use case. The open boot for camper shell allows you to join the truck cab and camper shell or utility box with a weather-sealed, flexible connection.
- What do you charge for shipping?
Here are the various charges for shipping both Domestic and International
Part 540 Compression Boot - Flap $19.98 Part 541 Accordion Boot $19.98 Part 543 Wide Accordion Boot $27.76 Part 544 Extra Wide Accordion Boot $27.76 Part 545 Compression boot - Bulb $19.98 Canada $76.95 International $110.00 - Can I get samples of the boot?
Yes, we offer a sample pack that includes each of the boot styles. Getting a sample will help you know and understand how the boot installs and attaches to your vehicle or special project. To order a sample pack go to Boot Sample
