Leer Compression Boots
How to Choose the Right Rubber Boot Seal
You can purchase rubber boot material for your special project. This seal is extruded from long-lasting EPDM synthetic rubber compound and incorporates a pliable spring steel clip for fastening to any rim. This material is available by the foot. To determine how much you require measure the distance around your cab opening. You have three choices of rubber to use for waterproofing your cabs together.
Tips for Getting the Right Fit
To ascertain how much you need measure the length around your cab opening. It is important that both openings are exactly the equal size. Make sure to measure the opening before ordering. Every installation is different.
Universal Fit: Compatible Rubber Seals for Trucks and Rigs
This rubber boot seal is frequently used in cab pass-through conversions. It's designed for most light-duty trucks. Whether you're installing a camper shell or building a custom rig, this seal offers broad fitment and dependable performance for your cab connection project.
Leer Compression Boots Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Proven on Sleeper Cab Trucks | Successfully used between cab and sleeper on heavy-duty trucks | Ideal for semi trucks |
| Silicone-Friendly Seam Sealing | Easy to seal end joints with a small bead of silicone | Ensures total waterproofing where ends come together |
| Watertight Design | Keeps moisture and dust out, even in rough outdoor environments | Protects interior from water, wind and dust |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Can I keep my sliding windows and still use a ?
Unfortunately, no. The slider windows must be removed because the leer compression boots equires a clean flange or wall to attach. Sliders block access to this area.
- Do I need glue to install the accordion boot?
The rubber boot does not require glue for installation. It has a spring clip embedded in the rubber. When the boot is placed over a flange, the clip squeezes the rubber securely. The only optional gluing is at the seam using cyanoacrylate (SuperGlue). Avoid petroleum-based adhesives like rubber cement.
- I have a pickup that I cut out a section between the cab and the bed. Will your product work for the metal below the window, or is that material to thin?
Yes the boot will work for this situation
