Install Truck Boot
How to Choose the Right Rubber Boot Seal
You can buy rubber boot material for your special project. This seal is manufactured from hard-wearing EPDM synthetic rubber compound and contains a flexible spring steel clip for fastening to any flange. This material is sold by the foot. To ascertain how much you require measure the length around your cab opening. You get 3 options of rubber to apply for waterproofing your cabs together.
Quick and Easy Installation
Installing this rubber boot is easy and can be done with few tools. Just snap the seal firmly onto the edge of the window or pass through opening. This creates a tight connection between the two units. Whether you're off-roading, this seal blocks debris and maintains cabin integrity during your journey.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is critical for your vehicle project. This rubber boot stands out due to its top-grade construction and real-world reliability. We focus on providing products that surpass your expectations for long-term performance. Don't settle for flimsy seals, upgrade to one that's built to last.
Install Truck Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Compressed and Expanded Flex | Adapts to body movement and misalignments | Maintains seal during travel, loading, or frame shifts |
| Prevents Heat and Sound Transfer | Improves cab comfort by blocking wind and road noise | Useful for sleepers and audio builds |
| Forgiving Fit | Can accommodate minor mismatches in height and width | Useful for older vehicles or hand-cut openings |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- How is the accordion boot installed?
The boot slips into the opening between the truck cab and camper. Use clamps or sealant for a tight, weatherproof connection.
- What tools do I need to install ainstall truck boot?
Basic tools like a utility knife, heavy duty siccors, measuring tape, a soft mallet, are usually sufficient for installing a install truck boot.
- Is there a certain glue that can be used in conjunction with the accordion boot?
The rubber boot does not require glue for installation. This is because there is a spring clip embedded it the rubber. When the boot is placed over a flange the spring clip squeezes the rubber securely. The only place you may want to glue the boot is where it meets. This is however optional. To glue the seam where the two ends meet, you can use cyanoacrylate (i.e. SuperGlue). Do not use any petroleum based glues as it will react negatively to the rubber. (i.e. rubber cement). See Installing Accordion Boot for more details.
