How To Seal A Cap To A Cable
How to Choose the Right Rubber Boot Seal
You can obtain rubber boot material for your special project. This seal is extruded from resilient EPDM synthetic rubber substance and uses a flexible spring steel clip for fastening to any flange. This material is available by the foot. To determine how much you need measure the distance encircling your cab opening. You get 3 options of rubber to make use of for waterproofing your cabs together.
Tips for Getting the Right Fit
To ascertain how much you require measure the length around your cab opening. It is essential that both openings are exactly the equal size. Make sure to measure the opening before ordering. Every installation is different.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is engineered to withstand rugged conditions such as heat. It's tailored for both weekend getaways. Compared to standard seals, this material offers more protection. It's a smart investment for anyone looking to preserve their truck cab connection with a dependable sealing solution.
How To Seal A Cap To A Cable Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| U-Channel Orientation Consistency | Both U-shaped edges face the same way for easier installation | Helps avoid confusion during install, especially for beginners |
| Adapts to Slightly Uneven Openings | Flexible enough to seal even when openings aren’t perfectly aligned | Even though it is best that the opening match exactly there is some wiggle room to make minor adjustments for custom truck and canopy installations |
| Easy DIY Installation | Simple to install with basic tools | Weekend warrior friendly; ideal for personal projects |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Will the how to seal a cap to a cable work on a walk-through truck conversion?
Yes! This is a perfect use case. The how to seal a cap to a cable allows you to join the truck cab and camper shell or utility box with a weather-sealed, flexible connection.
- I am making a walk through conversion on my pickup truck to allow access in the bed. I want to to cut the wall between the cab and bed to make one continuous passenger cabin to the camper shell. I also want something that looks decent, and will last. Will the accordion boot work in this situation?
Yes, the accordion boot will work for you in this type of installation. For more details on how to create and seal a cut through go to the Cut Through FAQ page for more details
- Will one of these work on both sliding windows on truck & cap? I don't want to remove either sliding window.
In order for the boot to attach to the vehicle there must be some sort of thin wall or flange. Keeping the slider window will cover any flange or thin wall. In short you will not be able to use any or the boots if you keep the sliding windows in place as there will be no mechanical method to install the boot.
