Crl Accordion Boot Seals
How to Choose the Right Rubber Boot Seal
You can acquire rubber boot material for your special project. This seal is manufactured from long-lasting EPDM synthetic rubber substance and contains a flexible spring steel clip for affixing to any rim. This material is available by the foot. To determine how much you need measure the length encircling your cab opening. You get 3 options of rubber to apply for sealing your cabs together.
Tips for Getting the Right Fit
To determine how much you want measure the distance around your cab opening. It is essential that both openings are exactly the same size. Make sure to measure the opening before ordering. Every installation is unique.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is crafted to survive rugged conditions such as cold. It's ideal for both daily use. Compared to standard seals, this material retains flexibility. It's a solid choice for anyone looking to preserve their truck cab connection with a dependable sealing solution.
Crl Accordion Boot Seals Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Watertight Design | Keeps moisture and dust out, even in rough outdoor environments | Protects interior from water, wind and dust |
| Multi-Vehicle Fit | Works on trucks, vans, semi cabs, and custom enclosures | Versatile for commercial and recreational conversions |
| Compressed and Expanded Flex | Adapts to body movement and misalignments | Maintains seal during travel, loading, or frame shifts |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Can I install the crl accordion boot seals by myself?
Most users successfully install the crl accordion boot seals with basic tools, soap solution, and occasionally a helper for positioning.
- Do I need glue to install the accordion boot?
The rubber boot does not require glue for installation. It has a spring clip embedded in the rubber. When the boot is placed over a flange, the clip squeezes the rubber securely. The only optional gluing is at the seam using cyanoacrylate (SuperGlue). Avoid petroleum-based adhesives like rubber cement.
- What if I don't like something?
Your complete satisfaction is very important to us! We guarantee that if you do not like your merchandise, or it is broken, you can return it and get your money back. This 100% satisfaction money-back guarantee is good for 30 days.
