Camper Shell With A Boot
How to Choose the Right Rubber Boot Seal
You can purchase rubber boot material for your special project. This seal is manufactured from long-lasting EPDM synthetic rubber substance and integrates a bendable spring steel clip for affixing to any flange. This material is available by the foot. To determine how much you need measure the distance around your cab opening. You have several options of rubber to use for sealing your cabs together.
Quick and Easy Installation
Installing this rubber boot is easy and requires minimal tools. Just attach the seal tightly onto the thin wall of the window or pass through opening. This ensures a tight connection between the two units. Whether you're hauling, this seal keeps out moisture and helps cabin integrity during your journey.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is crucial for your vehicle project. This rubber boot excels due to its industrial-strength construction and real-world reliability. We focus on providing products that exceed your needs for long-term value. Don't settle for inferior seals, upgrade to one that's built to last.
Camper Shell With A Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| EPDM Sponge Rubber Construction | Flexible, resilient seal that withstands weather and aging | Ideal for trucks, RVs, and sleeper cabs exposed to elements |
| Aesthetic Finish | Clean, professional appearance enhances your build’s look | Great for show rigs, restorations, or resale appeal |
| Fast, Reliable Shipping | Quick turnaround when time-sensitive installs are needed | Helpful for last-minute road trip or show prep |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Does the camper shell with a bootrequire glue to install?
No glue is required. The camper shell with a boot has a spring clip embedded in the EPDM rubber that clamps onto a thin flange. You can optionally glue the seam using cyanoacrylate (SuperGlue), but avoid petroleum-based adhesives.
- Will one of these work on both sliding windows on truck & cap? I don't want to remove either sliding window.
In order for the boot to attach to the vehicle there must be some sort of thin wall or flange. Keeping the slider window will cover any flange or thin wall. In short you will not be able to use any or the boots if you keep the sliding windows in place as there will be no mechanical method to install the boot.
- What do you recommend is the smallest radius cut out in the corners of the opening?
The recommended minimum radius is 1 inch for the boot for corners.
