Cab To Cap Accordion Seal
How to Choose the Right Rubber Boot Seal
You can get rubber boot material for your special project. This seal is manufactured from tough EPDM synthetic rubber substance and has a flexible spring steel clip for affixing to any rim. This material is available by the foot. To determine how much you require measure the length encircling your cab opening. You have 3 alternatives of rubber to use for waterproofing your cabs together.
Quick and Easy Installation
Installing this rubber boot is user-friendly and requires minimal tools. Just clip the seal firmly onto the rim of the window or pass through opening. This creates a tight connection between the two units. Regardless of whether you're hauling, this seal keeps out dust and maintains a dry space during your journey.
Universal Fit: Compatible Rubber Seals for Trucks and Rigs
This rubber boot seal is commonly used in truck modifications. It's works with most mid-size trucks. Whether you're repairing a camper shell or building a personalized rig, this seal offers universal fitment and dependable performance for your cab connection project.
Cab To Cap Accordion Seal Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Flexible Bellows Design | Absorbs vibration and road movement without cracking | Great for off-road and long-haul driving |
| U-Channel Orientation Consistency | Both U-shaped edges face the same way for easier installation | Helps avoid confusion during install, especially for beginners |
| Adapts to Slightly Uneven Openings | Flexible enough to seal even when openings aren’t perfectly aligned | Even though it is best that the opening match exactly there is some wiggle room to make minor adjustments for custom truck and canopy installations |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Does the cab to cap accordion seal allow for movement between the truck and camper?
Yes, the accordion-style folds are designed to flex, allowing for some movement and vibration without breaking the seal.
- Will your product work for metal below the window that is too thin?
Yes, the boot will work. Just ensure there is a flange for the clip to attach.
- I have a pickup that I cut out a section between the cab and the bed. Will your product work for the metal below the window, or is that material to thin?
Yes the boot will work for this situation
