Boot For Between Canopy And Truck Slider Window
How to Choose the Right Rubber Boot Seal
You can acquire rubber boot material for your special project. This seal is extruded from robust EPDM synthetic rubber substance and contains a bendable spring steel clip for affixing to any flange. This material is available by the foot. To find how much you require measure the distance around your cab opening. You get several alternatives of rubber to employ for sealing your cabs together.
Tips for Getting the Right Fit
To ascertain how much you require measure the space around your cab opening. It is important that both openings are exactly the matching size. Make sure to measure the opening before ordering. Every installation is unique.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is engineered to survive rugged conditions such as cold. It's ideal for both daily use. Compared to standard seals, this material lasts longer. It's a reliable option for anyone looking to enhance their truck cab connection with a dependable sealing solution.
Boot For Between Canopy And Truck Slider Window Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Powder-Coated Friendly Channel | Seals well even on painted or coated surfaces | Ensures compatibility with modified or custom trucks |
| Audio Blow-Through Compatible | Perfect for stereo mods and custom subwoofer enclosures | Used in high-performance truck audio builds |
| Weather-Tested Seal | Handles rainstorms without leaks or performance loss | Reliable weather barrier for daily-use trucks or RVs |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Will the boot for between canopy and truck slider window work with thin metal or wood frames?
Yes, but there must be a flange no thicker than 3/16". For wood or thick materials, add a metal strip (like aluminum flat bar) around the opening for the boot for between canopy and truck slider window to grip.
- I am wondering if the compression boot can be trimmed to fit around the third brake light?
You cannot cut the boot to fit around the 3rd brake light. Here are a couple of things you may want to do.
- Remove the brake light and cover the opening with a thin plate.
- Instead of installing the boot to the shell, install the boot into the truck window opening. Do this only if you remove the rear window.
- I am making a walk through conversion on my pickup truck to allow access in the bed. I want to to cut the wall between the cab and bed to make one continuous passenger cabin to the camper shell. I also want something that looks decent, and will last. Will the accordion boot work in this situation?
Yes, the accordion boot will work for you in this type of installation. For more details on how to create and seal a cut through go to the Cut Through FAQ page for more details
