Accordion Rv Gasket
How to Choose the Right Rubber Boot Seal
You can purchase rubber boot material for your special project. This seal is extruded from resilient EPDM synthetic rubber substance and has a flexible spring steel clip for attaching to any flange. This material is available by the foot. To find how much you need measure the length encircling your cab opening. You have three choices of rubber to employ for waterproofing your cabs together.
Quick and Easy Installation
Installing this rubber boot is simple and requires minimal tools. Just press the seal tightly onto the frame of the window or pass through opening. This forms a watertight connection between the two units. Whether you're adventuring, this seal blocks moisture and helps cabin integrity during your journey.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is critical for your vehicle project. This rubber boot excels due to its industrial-strength construction and customer-approved reliability. We take pride on providing products that exceed your needs for long-term performance. Don't settle for low-end seals, upgrade to one that's built to last.
Accordion Rv Gasket Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Audio Blow-Through Compatible | Perfect for stereo mods and custom subwoofer enclosures | Used in high-performance truck audio builds |
| UV & Weather Resistant | Withstands sun, rain, and temperature changes without cracking | Long-term durability for vehicles stored outdoors |
| Silicone-Friendly Seam Sealing | Easy to seal end joints with a small bead of silicone | Ensures total waterproofing where ends come together |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- What is an accordion boot?
An accordion boot is a flexible rubber connector that creates a weatherproof seal between two compartments, such as a truck cab and camper shell.
- Is there a certain glue that can be used in conjunction with the accordion boot?
The rubber boot does not require glue for installation. This is because there is a spring clip embedded it the rubber. When the boot is placed over a flange the spring clip squeezes the rubber securely. The only place you may want to glue the boot is where it meets. This is however optional. To glue the seam where the two ends meet, you can use cyanoacrylate (i.e. SuperGlue). Do not use any petroleum based glues as it will react negatively to the rubber. (i.e. rubber cement). See Installing Accordion Boot for more details.
- Is it suitable for sealing between an airbag mounted truck cab and the body hard mounted to chassis rails on a truck?
As long as there is some sort of flange or wall to install the boot it should work. The thickness of the flange should not exceed 3/16" (4.7625mm) The accordion design allows for independent movement or flex between the cab bodies.
