Truck Canopy Accordion Boot
How to Choose the Right Rubber Boot Seal
You can obtain rubber boot material for your special project. This seal is manufactured from durable EPDM synthetic rubber substance and integrates a bendable spring steel clip for fastening to any flange. This material is sold by the foot. To ascertain how much you require measure the length encircling your cab opening. You have three alternatives of rubber to apply for sealing your cabs together.
Quick and Easy Installation
Installing this rubber boot is simple and requires minimal tools. Just secure the seal tightly onto the flange of the window or pass through opening. This creates a watertight connection between the two units. Even if you're hauling, this seal prevents debris and helps a dry space during your journey.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is engineered to survive extreme conditions such as sunlight. It's perfect for both commercial fleets. Compared to standard seals, this material performs better. It's a reliable option for anyone looking to upgrade their truck cab connection with a dependable sealing solution.
Truck Canopy Accordion Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Made in the USA | High manufacturing standards and local support | Ideal for buyers who value American-made products |
| Watertight Design | Keeps moisture and dust out, even in rough outdoor environments | Protects interior from water, wind and dust |
| Reusable with Careful Removal | Can be reinstalled without damage if no adhesive used | Ideal for resprays, upgrades, or camper swaps |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Does the truck canopy accordion boot require glue to install?
No glue is required. The truck canopy accordion boot has a spring clip embedded in the EPDM rubber that clamps onto a thin flange. You can optionally glue the seam using cyanoacrylate (SuperGlue), but avoid petroleum-based adhesives.
- What if the camper shell opening is larger than my truck window?
If the shell opening is larger, the truck canopy accordion boot may not work. You’ll either need to modify the opening or consider a compression boot instead, which is more forgiving in such situations.
- Can I get samples of the boot?
Yes, we offer a sample pack that includes each of the boot styles. Getting a sample will help you know and understand how the boot installs and attaches to your vehicle or special project. To order a sample pack go to Boot Sample
