How to Choose the Right Rubber Boot Seal
You can acquire rubber boot material for your special project. This seal is extruded from robust EPDM synthetic rubber substance and has a bendable spring steel clip for fastening to any rim. This material is sold by the foot. To decide how much you require measure the length around your cab opening. You have 3 options of rubber to employ for sealing your cabs together.
Quick and Easy Installation
Installing this rubber boot is straightforward and requires minimal tools. Just fit the seal firmly onto the frame of the window or pass through opening. This forms a watertight connection between the two units. Even if you're traveling, this seal blocks debris and maintains a dry space during your journey.
Universal Fit: Compatible Rubber Seals for Trucks and Rigs
This rubber boot seal is widely used in vehicle sealing applications. It's works with most light-duty trucks. Whether you're installing a camper shell or building a DIY rig, this seal offers universal fitment and dependable performance for your cab connection project.
Window Accordion Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Powder-Coated Friendly Channel | Seals well even on painted or coated surfaces | Ensures compatibility with modified or custom trucks |
| Watertight Design | Keeps moisture and dust out, even in rough outdoor environments | Protects interior from water, wind and dust |
| Affordable, High-Value Solution | Great quality at a competitive price point | Cost-effective choice for budget-conscious builders |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- How weatherproof is the window accordion?
The EPDM accordion boot creates an airtight, watertight seal when installed correctly. It's designed to keep rain, dust, and wind out — ideal for camper conversions and pass-throughs.
- Can I custom trim a window accordion to fit my setup?
You can trim the length to fit your application, but altering the shape, corners, or embedded clip area is not recommended.
- I have a truck that I want to install a camper shell on. The shell has a slider and I will need to remove the rear cab window. Is there a procedure when using a boot that insures a watertight seal?
To insure a water tight seal you should consider the accordion boot. In order to use the accordion boot there are a few condition that need to be met.
- 1) Both opening must be the exact same size
- 2) there must be some sort of thin wall or flange to attach the boot. This can be the fiberglass wall or pinch weld around the window opening.
- 3) Both windows will need to be removed.
