How to Choose the Right Rubber Boot Seal

You can get rubber boot material for your special project. This seal is extruded from robust EPDM synthetic rubber substance and uses a bendable spring steel clip for affixing to any rim. This material is available by the foot. To ascertain how much you need measure the length around your cab opening. You get 3 alternatives of rubber to apply for sealing your cabs together.

Tips for Getting the Right Fit

To specify how much you require measure the length around your cab opening. It is vital that both openings are perfectly the equal size. Make sure to measure the opening before ordering. Every installation is unique.

Why EPDM Rubber Is the Best Choice for Long-Lasting Seals

The EPDM rubber seal is engineered to handle severe conditions such as sunlight. It's tailored for both daily use. Compared to cheaper seals, this material retains flexibility. It's a reliable option for anyone looking to enhance their truck cab connection with a dependable sealing solution.

Window Accordion Features and Benefits

Feature Benefit Use Case
Made in the USA High manufacturing standards and local support Ideal for buyers who value American-made products
Embedded Steel Spring Clip Maintains a secure grip on flanges without adhesive Stable connection between cab and shell
Watertight Design Keeps moisture and dust out, even in rough outdoor environments Protects interior from water, wind and dust

Order Form

To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.

Accordion Boot - Part Number 541

Accordion Boot

The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.

How Accordion Boot Works Animation

$8.95 per foot

In Stock

Order 541

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Compression Boot - Part Number 540

Compression Boot

Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.

How Compression Boot Works Animation

$7.95 per foot

In Stock

Order 540

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Extra Wide Accordion Boot - Part Number 543

Extra Wide Accordion Boot

The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.

$11.50 per foot

In Stock

Order 543

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Accordion Boot - Ultra Wide 10" Part Number 544

Accordion Boot 10 inch wide

The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.

$13.90 per foot

In Stock

Order 544

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Accordion Boot 15 - Part Number 546

Extra Wide Accordion Boot

The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.

$16.50 per foot

In Stock

Order 546

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Compression Bulb Seal - Part Number 545

Compression Bulb Seal

Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.

$7.95 per foot

In Stock

Order 545

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Frequently Asked Questions

  • How long does an accordion boot last?

    With proper installation and care, EPDM accordion boots can last for years under normal driving conditions.

  • What tools do I need to install awindow accordion?

    Basic tools like a utility knife, heavy duty siccors, measuring tape, a soft mallet, are usually sufficient for installing a window accordion.

  • I am making a walk through conversion on my pickup truck to allow access in the bed. I want to to cut the wall between the cab and bed to make one continuous passenger cabin to the camper shell. I also want something that looks decent, and will last. Will the accordion boot work in this situation?

    Yes, the accordion boot will work for you in this type of installation. For more details on how to create and seal a cut through go to the Cut Through FAQ page for more details
