Truck Window Boot Truck Cap
How to Choose the Right Rubber Boot Seal
You can purchase rubber boot material for your special project. This seal is extruded from tough EPDM synthetic rubber substance and incorporates a bendable spring steel clip for fastening to any rim. This material is available by the foot. To specify how much you require measure the length encircling your cab opening. You have 3 alternatives of rubber to apply for waterproofing your cabs together.
Tips for Getting the Right Fit
To specify how much you want measure the length around your cab opening. It is essential that both openings are exactly the equal size. Make sure to measure the opening before ordering. Every installation is unique.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is essential for your vehicle project. This rubber boot delivers due to its premium construction and real-world reliability. We focus on providing products that meet your demands for long-term durability. Don't settle for cheap seals, upgrade to one that's made for the road.
Truck Window Boot Truck Cap Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Affordable, High-Value Solution | Great quality at a competitive price point | Cost-effective choice for budget-conscious builders |
| Proven on Sleeper Cab Trucks | Successfully used between cab and sleeper on heavy-duty trucks | Ideal for semi trucks |
| Embedded Steel Spring Clip | Maintains a secure grip on flanges without adhesive | Stable connection between cab and shell |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- How long will my truck window boot truck cap last?
EPDM rubber is extremely durable, UV-resistant, and built to last for years. Proper installation can extend its lifespan significantly.
- What if I’m not satisfied with my truck window boot truck cap?
We offer a 30-day money-back guarantee. If you're not satisfied, simply contact customer service and return the product.
- I have a Ford F150 with a LEER top. I an pretty sure the accordion seal is the correct option but the warning that the opening must be an exact match has me concerned. It looks like the truck opening is larger at the lower corners but until the window is removed, who knows? Am I on safe ground getting the accordion seal for this application?
The accordion boot only stretches one direction. There is a metal clip embedded in the rubber that allow you to attach the boot to the fiberglass/sheet metal, Therefore both window openings must be the same size. If the opening in the shell is smaller you can cut and trim the fiberglass to match the truck's window opening.
