Truck Shell Boot Seal

Only Buy What You Need - Rubber Boot Material Sold by the Foot
This product is purchased by the foot. Unlike other organizations that require you to purchase more than you require. You buy the correct quantity you require. No waste.
Tips for Getting the Right Fit
To specify how much you want measure the space around your cab opening. It is vital that both openings are accurately the same size. Make sure to measure the opening before ordering. Every installation is unique.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is engineered to survive rugged conditions such as cold. It's ideal for both off-grid builds. Compared to low-grade seals, this material lasts longer. It's a solid choice for anyone looking to enhance their truck cab connection with a dependable sealing solution.
Truck Shell Boot Seal Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Adapts to Slightly Uneven Openings | Flexible enough to seal even when openings aren’t perfectly aligned | Even though it is best that the opening match exactly there is some wiggle room to make minor adjustments for custom truck and canopy installations |
| Multi-Vehicle Fit | Works on trucks, vans, semi cabs, and custom enclosures | Versatile for commercial and recreational conversions |
| Custom Length | Get the exact amount you need with no waste or shortages | Great for DIY box truck or custom overland builds |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541

The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.

$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540

Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.

$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543

The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544

The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546

The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545

Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Can I install a truck shell boot seal in cold weather?Yes, but it's best to warm the truck shell boot seal slightly beforehand. Cold temperatures may make the rubber less flexible and harder to manipulate during installation.
- How do I know if I need a truck shell boot seal or a compression boot?Use a truck shell boot sealwhen both openings are identical in size and shape. Use a compression boot if there are size differences or no solid flange available.
- Do I need glue to install the accordion boot?The rubber boot does not require glue for installation. It has a spring clip embedded in the rubber. When the boot is placed over a flange, the clip squeezes the rubber securely. The only optional gluing is at the seam using cyanoacrylate (SuperGlue). Avoid petroleum-based adhesives like rubber cement.
