Truck Cap Compression Boot
How to Choose the Right Rubber Boot Seal
You can buy rubber boot material for your special project. This seal is manufactured from hard-wearing EPDM synthetic rubber compound and incorporates a bendable spring steel clip for affixing to any rim. This material is available by the foot. To determine how much you need measure the length encircling your cab opening. You get three alternatives of rubber to apply for sealing your cabs together.
Tips for Getting the Right Fit
To ascertain how much you require measure the distance around your cab opening. It is essential that both openings are exactly the equal size. Make sure to measure the opening before ordering. Every installation is unique.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is designed to endure extreme conditions such as sunlight. It's tailored for both off-grid builds. Compared to low-grade seals, this material retains flexibility. It's a reliable option for anyone looking to upgrade their truck cab connection with a dependable sealing solution.
Truck Cap Compression Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Powder-Coated Friendly Channel | Seals well even on painted or coated surfaces | Ensures compatibility with modified or custom trucks |
| Supports Walk-Through Conversions | Lets you convert separate spaces into one continuous interior | Used in van builds, campers, and custom sleeper cabs |
| Urethane Adhesive Compatible | Allows permanent seal when needed for high-stress areas | Used in high-vibration or heavy-use applications |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Will the truck cap compression boot work on a walk-through truck conversion?
Yes! This is a perfect use case. The truck cap compression boot allows you to join the truck cab and camper shell or utility box with a weather-sealed, flexible connection.
- Will a truck cap compression boot reduce road noise?
Yes, the air-tight seal created by the truck cap compression boot helps block wind noise and some road vibrations between the cab and camper.
- Is it suitable for sealing between an airbag mounted truck cab and the body hard mounted to chassis rails on a truck?
As long as there is some sort of flange or wall to install the boot it should work. The thickness of the flange should not exceed 3/16" (4.7625mm) The accordion design allows for independent movement or flex between the cab bodies.
