Truck Cab Window To Cap Boot
How to Choose the Right Rubber Boot Seal
You can get rubber boot material for your special project. This seal is extruded from robust EPDM synthetic rubber substance and integrates a bendable spring steel clip for affixing to any flange. This material is sold by the foot. To specify how much you need measure the distance around your cab opening. You get several options of rubber to make use of for waterproofing your cabs together.
Tips for Getting the Right Fit
To specify how much you want measure the distance around your cab opening. It is essential that both openings are precisely the same size. Make sure to measure the opening before ordering. Every installation is unique.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is critical for your vehicle project. This rubber boot stands out due to its superior construction and real-world reliability. We take pride on providing products that surpass your demands for long-term durability. Don't settle for low-end seals, upgrade to one that's made for the road.
Truck Cab Window To Cap Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Embedded Steel Spring Clip | Maintains a secure grip on flanges without adhesive | Stable connection between cab and shell |
| Prevents Heat and Sound Transfer | Improves cab comfort by blocking wind and road noise | Useful for sleepers and audio builds |
| Trusted by Pros and DIYers | Field-tested by thousands in real-world applications | Confidence in product from verified reviews and installs |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Will the truck cab window to cap boot work with thin metal or wood frames?
Yes, but there must be a flange no thicker than 3/16". For wood or thick materials, add a metal strip (like aluminum flat bar) around the opening for the truck cab window to cap bootto grip.
- Can I order a sample of the truck cab window to cap boot?
Yes, you can order a sample pack that includes all boot types. It’s a great way to test fit and feel before committing to a full-length order.
- Will one of these work on both sliding windows on truck & cap? I don't want to remove either sliding window.
In order for the boot to attach to the vehicle there must be some sort of thin wall or flange. Keeping the slider window will cover any flange or thin wall. In short you will not be able to use any or the boots if you keep the sliding windows in place as there will be no mechanical method to install the boot.
