Truck Cab To Camper Shell Boot
How to Choose the Right Rubber Boot Seal
You can purchase rubber boot material for your special project. This seal is extruded from tough EPDM synthetic rubber substance and uses a flexible spring steel clip for fastening to any flange. This material is sold by the foot. To decide how much you need measure the distance around your cab opening. You get three alternatives of rubber to employ for sealing your cabs together.
Tips for Getting the Right Fit
To determine how much you require measure the space around your cab opening. It is imperative that both openings are exactly the same size. Make sure to measure the opening before ordering. Every installation is different.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is developed to handle challenging conditions such as sunlight. It's suitable for both commercial fleets. Compared to low-grade seals, this material retains flexibility. It's a reliable option for anyone looking to preserve their truck cab connection with a dependable sealing solution.
Truck Cab To Camper Shell Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Made in the USA | High manufacturing standards and local support | Ideal for buyers who value American-made products |
| Custom Length | Get the exact amount you need with no waste or shortages | Great for DIY box truck or custom overland builds |
| No Sealant Required | Cleaner installation with easy removal if needed | Perfect for quick and easy installs |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Can the truck cab to camper shell boot be painted?
We only sell black boots, but EPDM rubber can be painted using an acrylic roof coating rated for EPDM. Avoid latex and petroleum-based paints.
- Can I install the truck cab to camper shell boot by myself?
Most users successfully install the truck cab to camper shell boot with basic tools, soap solution, and occasionally a helper for positioning.
- Will your product work for metal below the window that is too thin?
Yes, the boot will work. Just ensure there is a flange for the clip to attach.
