How to Choose the Right Rubber Boot Seal

You can buy rubber boot material for your special project. This seal is manufactured from durable EPDM synthetic rubber compound and contains a bendable spring steel clip for attaching to any rim. This material is available by the foot. To specify how much you need measure the distance around your cab opening. You have several alternatives of rubber to employ for waterproofing your cabs together.

Tips for Getting the Right Fit

To specify how much you want measure the distance around your cab opening. It is imperative that both openings are precisely the same size. Make sure to measure the opening before ordering. Every installation is unique.

Why EPDM Rubber Is the Best Choice for Long-Lasting Seals

The EPDM rubber seal is engineered to survive severe conditions such as UV exposure. It's tailored for both daily use. Compared to low-grade seals, this material offers more protection. It's a smart investment for anyone looking to enhance their truck cab connection with a dependable sealing solution.

Truck Accordion Boots Features and Benefits

Feature Benefit Use Case
Compressed and Expanded Flex Adapts to body movement and misalignments Maintains seal during travel, loading, or frame shifts
Watertight Design Keeps moisture and dust out, even in rough outdoor environments Protects interior from water, wind and dust
Custom Length Get the exact amount you need with no waste or shortages Great for DIY box truck or custom overland builds

Order Form

To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.

Accordion Boot - Part Number 541

Accordion Boot

The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.

How Accordion Boot Works Animation

$8.95 per foot

In Stock

Order 541

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Compression Boot - Part Number 540

Compression Boot

Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.

How Compression Boot Works Animation

$7.95 per foot

In Stock

Order 540

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Extra Wide Accordion Boot - Part Number 543

Extra Wide Accordion Boot

The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.

$11.50 per foot

In Stock

Order 543

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Accordion Boot - Ultra Wide 10" Part Number 544

Accordion Boot 10 inch wide

The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.

$13.90 per foot

In Stock

Order 544

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Accordion Boot 15 - Part Number 546

Extra Wide Accordion Boot

The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.

$16.50 per foot

In Stock

Order 546

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Compression Bulb Seal - Part Number 545

Compression Bulb Seal

Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.

$8.25 per foot

In Stock

Order 545

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Frequently Asked Questions

  • How long does it take to receive my truck accordion boots rder?

    Delivery typically takes 3 to 10 days depending on your location and order volume.

  • How much will I need?

    This material is sold by the foot. Unlike other companies that force you to buy more than you need. You get the exact amount you need. No waste. To determine how much you need measure the distance around your cab opening. It is important that both openings are exactly the same size. The average full-size pickup truck rear window opening is approximately 13 - 14 feet around. The average mini-truck is approximately 10 feet around the window opening.

  • Is it suitable for sealing between an airbag mounted truck cab and the body hard mounted to chassis rails on a truck?

    As long as there is some sort of flange or wall to install the boot it should work. The thickness of the flange should not exceed 3/16" (4.7625mm) The accordion design allows for independent movement or flex between the cab bodies.
