Trail Fx Truck Boot
How to Choose the Right Rubber Boot Seal
You can obtain rubber boot material for your special project. This seal is extruded from hard-wearing EPDM synthetic rubber substance and contains a bendable spring steel clip for fastening to any flange. This material is available by the foot. To ascertain how much you require measure the length around your cab opening. You get several alternatives of rubber to apply for sealing your cabs together.
Tips for Getting the Right Fit
To ascertain how much you need measure the distance around your cab opening. It is essential that both openings are accurately the equal size. Make sure to measure the opening before ordering. Every installation is different.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is designed to resist harsh conditions such as heat. It's perfect for both off-grid builds. Compared to low-grade seals, this material performs better. It's a reliable option for anyone looking to preserve their truck cab connection with a dependable sealing solution.
Trail Fx Truck Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Aesthetic Finish | Clean, professional appearance enhances your build’s look | Great for show rigs, restorations, or resale appeal |
| Forgiving Fit | Can accommodate minor mismatches in height and width | Useful for older vehicles or hand-cut openings |
| U-Channel Orientation Consistency | Both U-shaped edges face the same way for easier installation | Helps avoid confusion during install, especially for beginners |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- How weatherproof is the trail fx truck boot?
The EPDM accordion boot creates an airtight, watertight seal when installed correctly. It's designed to keep rain, dust, and wind out — ideal for camper conversions and pass-throughs.
- I have a pickup that I cut out a section between the cab and the bed. Will your product work for the metal below the window, or is that material to thin?
Yes the boot will work for this situation
- I have a truck with a wood framed utility box and would like join the cab and box using the accordion boot. How to I attach the boot?
You will not be able to attach the boot material to the wood, It is too thick. The best way to remedy this is to add a flange to the box. This could be done with steel or aluminum flat bar, or something similar (i.e. sheet metal, fiberglass), installed around the perimeter of the opening to allow the boot to attach to the box
