Pickup Truck Cap Seal
How to Choose the Right Rubber Boot Seal
You can get rubber boot material for your special project. This seal is extruded from hard-wearing EPDM synthetic rubber substance and has a bendable spring steel clip for attaching to any rim. This material is available by the foot. To find how much you need measure the length around your cab opening. You get several choices of rubber to employ for waterproofing your cabs together.
Tips for Getting the Right Fit
To specify how much you require measure the distance around your cab opening. It is vital that both openings are precisely the same size. Make sure to measure the opening before ordering. Every installation is unique.
Universal Fit: Compatible Rubber Seals for Trucks and Rigs
This rubber boot seal is often used in cab pass-through conversions. It's works with most full-size trucks. Whether you're repairing a camper shell or building a bespoke rig, this seal offers flexible fitment and dependable performance for your cab connection project.
Pickup Truck Cap Seal Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Audio Blow-Through Compatible | Perfect for stereo mods and custom subwoofer enclosures | Used in high-performance truck audio builds |
| Embedded Steel Spring Clip | Maintains a secure grip on flanges without adhesive | Stable connection between cab and shell |
| Adapts to Slightly Uneven Openings | Flexible enough to seal even when openings aren’t perfectly aligned | Even though it is best that the opening match exactly there is some wiggle room to make minor adjustments for custom truck and canopy installations |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Can I install the pickup truck cap seal by myself?
Most users successfully install the pickup truck cap seal with basic tools, soap solution, and occasionally a helper for positioning.
- I am wondering if the compression boot can be trimmed to fit around the third brake light?
You cannot cut the boot to fit around the 3rd brake light. Here are a couple of things you may want to do.
- Remove the brake light and cover the opening with a thin plate.
- Instead of installing the boot to the shell, install the boot into the truck window opening. Do this only if you remove the rear window.
- I am getting a camper shell with a sliding glass window so I am taking the window out of my pickup and it looks like the Compression Boot would be what i need, I am wondering which is the best to get the Compression Boot - Part Number 540 or the Compression Bulb Seal - Part Number 545?
Both boot function the same. We carry both types as different cap manufacturers will use one or the other. But there are slight differences between the two styles.
The flap seal 540 is a single layer of rubber that presses against the cab. In order to seal the edge is a single straight flat edge.
The bulb seal 545 is different in this way. It has a rounded edge. the rubber is double walled with an empty cavity. The material is slightly softer and will conform to the shape of the truck.
Both seal perform similarly. When it come to which one it is really a matter of preference.
