Pickup Cab To Cap Boot
How to Choose the Right Rubber Boot Seal
You can buy rubber boot material for your special project. This seal is extruded from tough EPDM synthetic rubber compound and contains a bendable spring steel clip for fastening to any flange. This material is available by the foot. To determine how much you need measure the distance encircling your cab opening. You get three options of rubber to apply for waterproofing your cabs together.
Quick and Easy Installation
Installing this rubber boot is straightforward and can be done with few tools. Just press the seal tightly onto the edge of the window or pass through opening. This creates a weatherproof connection between the two units. Whether you're adventuring, this seal keeps out rain and ensures temperature control during your journey.
Universal Fit: Compatible Rubber Seals for Trucks and Rigs
This rubber boot seal is typically used in vehicle sealing applications. It's works with most full-size trucks. Whether you're retrofitting a camper shell or building a personalized rig, this seal offers versatile fitment and dependable performance for your cab connection project.
Pickup Cab To Cap Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| U-Channel Orientation Consistency | Both U-shaped edges face the same way for easier installation | Helps avoid confusion during install, especially for beginners |
| Adapts to Slightly Uneven Openings | Flexible enough to seal even when openings aren’t perfectly aligned | Even though it is best that the opening match exactly there is some wiggle room to make minor adjustments for custom truck and canopy installations |
| Audio Blow-Through Compatible | Perfect for stereo mods and custom subwoofer enclosures | Used in high-performance truck audio builds |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Will the pickup cab to cap boot work with thin metal or wood frames?
Yes, but there must be a flange no thicker than 3/16". For wood or thick materials, add a metal strip (like aluminum flat bar) around the opening for the pickup cab to cap bootto grip.
- I am installing a boot between a truck cab and utility box.The box is about 1/2" thick. Will the boot clips expand over that type of material?
The material will not stretch that far. The maximum size that flange can be is 3/16" to receive the rubber. One solution to consider is to use flat bar and attach that around the opening in the box. One thing you must also remember - both opening need to be the same size and similar in shape.
- How durable is the accordian rubber
This product is durable. For specific technical data on the rubber visit this page http://www.accordionboot.com/epdm-rubber-boot.php
