Pick Up Cap Window Boots
How to Choose the Right Rubber Boot Seal
You can buy rubber boot material for your special project. This seal is extruded from robust EPDM synthetic rubber compound and uses a flexible spring steel clip for affixing to any flange. This material is available by the foot. To find how much you require measure the length encircling your cab opening. You have several options of rubber to make use of for sealing your cabs together.
Tips for Getting the Right Fit
To find how much you need measure the distance around your cab opening. It is vital that both openings are exactly the equal size. Make sure to measure the opening before ordering. Every installation is unique.
Don't Settle for Less: Upgrade to a Seal Built for the Road
Choosing the right seal is crucial for your vehicle project. This rubber boot stands out due to its industrial-strength construction and customer-approved reliability. We take pride on providing products that exceed your expectations for long-term satisfaction. Don't settle for cheap seals, upgrade to one that's made for the road.
Pick Up Cap Window Boots Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| EPDM Sponge Rubber Construction | Flexible, resilient seal that withstands weather and aging | Ideal for trucks, RVs, and sleeper cabs exposed to elements |
| Adapts to Slightly Uneven Openings | Flexible enough to seal even when openings aren’t perfectly aligned | Even though it is best that the opening match exactly there is some wiggle room to make minor adjustments for custom truck and canopy installations |
| Fast, Reliable Shipping | Quick turnaround when time-sensitive installs are needed | Helpful for last-minute road trip or show prep |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- Does the pick up cap window bootsrequire glue to install?
No glue is required. The pick up cap window boots has a spring clip embedded in the EPDM rubber that clamps onto a thin flange. You can optionally glue the seam using cyanoacrylate (SuperGlue), but avoid petroleum-based adhesives.
- I have a truck with a wood framed utility box and would like join the cab and box using the accordion boot. How to I attach the boot?
You will not be able to attach the boot material to the wood, It is too thick. The best way to remedy this is to add a flange to the box. This could be done with steel or aluminum flat bar, or something similar (i.e. sheet metal, fiberglass), installed around the perimeter of the opening to allow the boot to attach to the box
- How thick is the accordion boot rubber?
The thickness of the rubber it is about 3/32" thick. (2.38mm).
