Per Shell Boot Gasket
Only Buy What You Need - Rubber Boot Material Sold by the Foot
This item is sold by the foot. Unlike other businesses that force you to buy more than you need. You purchase the correct amount you require. No waste.
Quick and Easy Installation
Installing this rubber boot is straightforward and requires minimal tools. Just snap the seal tightly onto the flange of the window or pass through opening. This creates a watertight connection between the two units. Even if you're adventuring, this seal keeps out rain and ensures cabin integrity during your journey.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is engineered to handle challenging conditions such as cold. It's ideal for both daily use. Compared to cheaper seals, this material offers more protection. It's a solid choice for anyone looking to preserve their truck cab connection with a dependable sealing solution.
Per Shell Boot Gasket Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Silicone-Friendly Seam Sealing | Easy to seal end joints with a small bead of silicone | Ensures total waterproofing where ends come together |
| Audio Blow-Through Compatible | Perfect for stereo mods and custom subwoofer enclosures | Used in high-performance truck audio builds |
| Watertight Design | Keeps moisture and dust out, even in rough outdoor environments | Protects interior from water, wind and dust |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- What if the camper shell opening is larger than my truck window?
If the shell opening is larger, the per shell boot gasket may not work. You’ll either need to modify the opening or consider a compression boot instead, which is more forgiving in such situations.
- How weatherproof is the per shell boot gasket?
The EPDM accordion boot creates an airtight, watertight seal when installed correctly. It's designed to keep rain, dust, and wind out — ideal for camper conversions and pass-throughs.
- I have a Ford F150 with a LEER top. I an pretty sure the accordion seal is the correct option but the warning that the opening must be an exact match has me concerned. It looks like the truck opening is larger at the lower corners but until the window is removed, who knows? Am I on safe ground getting the accordion seal for this application?
The accordion boot only stretches one direction. There is a metal clip embedded in the rubber that allow you to attach the boot to the fiberglass/sheet metal, Therefore both window openings must be the same size. If the opening in the shell is smaller you can cut and trim the fiberglass to match the truck's window opening.
