F150 Cap Boot
How to Choose the Right Rubber Boot Seal
You can purchase rubber boot material for your special project. This seal is extruded from tough EPDM synthetic rubber compound and contains a bendable spring steel clip for attaching to any rim. This material is sold by the foot. To specify how much you need measure the distance encircling your cab opening. You get several choices of rubber to apply for sealing your cabs together.
Quick and Easy Installation
Installing this rubber boot is easy and can be done with few tools. Just clip the seal tightly onto the thin wall of the window or pass through opening. This ensures a weatherproof connection between the two units. Whether you're camping, this seal keeps out dust and preserves cabin integrity during your journey.
Universal Fit: Compatible Rubber Seals for Trucks and Rigs
This rubber boot seal is frequently used in vehicle sealing applications. It's fits most mid-size trucks. Whether you're repairing a camper shell or building a personalized rig, this seal offers versatile fitment and dependable performance for your cab connection project.
F150 Cap Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| UV & Weather Resistant | Withstands sun, rain, and temperature changes without cracking | Long-term durability for vehicles stored outdoors |
| Fast, Reliable Shipping | Quick turnaround when time-sensitive installs are needed | Helpful for last-minute road trip or show prep |
| Multi-Vehicle Fit | Works on trucks, vans, semi cabs, and custom enclosures | Versatile for commercial and recreational conversions |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- What is the minimum corner radius I can use?
The recommended minimum radius for corners is 1 inch. Tighter corners may cause the f150 cap boot to bunch or kink.
- What’s the difference between the flap and bulb compression boot?
The flap version has a straight edge, while the bulb version includes a rounded, softer cushion for enhanced sealing and flexibility.
- I have a Ford F150 with a LEER top. I an pretty sure the accordion seal is the correct option but the warning that the opening must be an exact match has me concerned. It looks like the truck opening is larger at the lower corners but until the window is removed, who knows? Am I on safe ground getting the accordion seal for this application?
The accordion boot only stretches one direction. There is a metal clip embedded in the rubber that allow you to attach the boot to the fiberglass/sheet metal, Therefore both window openings must be the same size. If the opening in the shell is smaller you can cut and trim the fiberglass to match the truck's window opening.
