How to Choose the Right Rubber Boot Seal

You can get rubber boot material for your special project. This seal is manufactured from long-lasting EPDM synthetic rubber substance and uses a bendable spring steel clip for fastening to any rim. This material is sold by the foot. To determine how much you require measure the distance around your cab opening. You get three choices of rubber to apply for sealing your cabs together.

Quick and Easy Installation

Installing this rubber boot is simple and requires minimal tools. Just attach the seal firmly onto the frame of the window or pass through opening. This forms a tight connection between the two units. Even if you're camping, this seal prevents debris and preserves temperature control during your journey.

Universal Fit: Compatible Rubber Seals for Trucks and Rigs

This rubber boot seal is often used in truck modifications. It's compatible with most standard trucks. Whether you're installing a camper shell or building a personalized rig, this seal offers versatile fitment and dependable performance for your cab connection project.

Crl Automotive Accordion Boot Features and Benefits

Feature Benefit Use Case
Supports Walk-Through Conversions Lets you convert separate spaces into one continuous interior Used in van builds, campers, and custom sleeper cabs
Cleanable Surface Easy to wipe down or blow clean for reinstallation Using mild soap and water for cleaning maintenance
Multi-Vehicle Fit Works on trucks, vans, semi cabs, and custom enclosures Versatile for commercial and recreational conversions

Order Form

To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.

Accordion Boot - Part Number 541

Accordion Boot

The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.

How Accordion Boot Works Animation

$8.95 per foot

In Stock

Order 541

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Compression Boot - Part Number 540

Compression Boot

Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.

How Compression Boot Works Animation

$7.95 per foot

In Stock

Order 540

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Extra Wide Accordion Boot - Part Number 543

Extra Wide Accordion Boot

The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.

$11.50 per foot

In Stock

Order 543

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Accordion Boot - Ultra Wide 10" Part Number 544

Accordion Boot 10 inch wide

The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.

$13.90 per foot

In Stock

Order 544

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Accordion Boot 15 - Part Number 546

Extra Wide Accordion Boot

The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.

$16.50 per foot

In Stock

Order 546

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Compression Bulb Seal - Part Number 545

Compression Bulb Seal

Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.

$8.25 per foot

In Stock

Order 545

  1. Enter the total amount of feet of boot material you need in the text box
  2. Check your entries, then click on the "Order Now" button.

Frequently Asked Questions

  • What is the minimum corner radius I can use?

    The recommended minimum radius for corners is 1 inch. Tighter corners may cause the crl automotive accordion boot to bunch or kink.

  • Is the crl automotive accordion boot reusable if I remove it?

    While technically reusable, removal often deforms the material or compromises the embedded clip, so we recommend replacing it if removed.

  • I have a truck that I want to install a camper shell on. The shell has a slider and I will need to remove the rear cab window. Is there a procedure when using a boot that insures a watertight seal?

    To insure a water tight seal you should consider the accordion boot. In order to use the accordion boot there are a few condition that need to be met.

    • 1) Both opening must be the exact same size
    • 2) there must be some sort of thin wall or flange to attach the boot. This can be the fiberglass wall or pinch weld around the window opening.
    • 3) Both windows will need to be removed.
    In regards to condition 1, both opening must be exactly the same you can run into an issue if the camper shell opening is larger than the trucks window opening. You may need to build up the fiberglass. We do offer the compression boot as a concession for situations where the accordion boot will not work.
