Camper Window Seal Boot
How to Choose the Right Rubber Boot Seal
You can buy rubber boot material for your special project. This seal is manufactured from heavy-duty EPDM synthetic rubber compound and integrates a pliable spring steel clip for attaching to any rim. This material is sold by the foot. To specify how much you require measure the length around your cab opening. You get three alternatives of rubber to apply for waterproofing your cabs together.
Quick and Easy Installation
Installing this rubber boot is easy and requires minimal tools. Just secure the seal firmly onto the lip of the window or pass through opening. This creates a watertight connection between the two units. Regardless of whether you're off-roading, this seal prevents wind and ensures interior comfort during your journey.
Why EPDM Rubber Is the Best Choice for Long-Lasting Seals
The EPDM rubber seal is crafted to survive severe conditions such as UV exposure. It's tailored for both commercial fleets. Compared to low-grade seals, this material retains flexibility. It's a reliable option for anyone looking to upgrade their truck cab connection with a dependable sealing solution.
Camper Window Seal Boot Features and Benefits
| Feature | Benefit | Use Case |
|---|---|---|
| Prevents Heat and Sound Transfer | Improves cab comfort by blocking wind and road noise | Useful for sleepers and audio builds |
| Weather-Tested Seal | Handles rainstorms without leaks or performance loss | Reliable weather barrier for daily-use trucks or RVs |
| Fast, Reliable Shipping | Quick turnaround when time-sensitive installs are needed | Helpful for last-minute road trip or show prep |
Order Form
To begin your order just enter the total amount of feet of boot material you need in the appropriate box next to the item you want to order below. Check your entries then click on the "Order Now " button.
Accordion Boot - Part Number 541
The accordion boot is designed for cabs where you take out the truck window. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$8.95 per foot
In Stock
Order 541
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Boot - Part Number 540
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$7.95 per foot
In Stock
Order 540
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Extra Wide Accordion Boot - Part Number 543
The extra wide accordion boot is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$11.50 per foot
In Stock
Order 543
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot - Ultra Wide 10" Part Number 544
The Ultra Wide 10 Inch accordion boot is designed for very wide gaps between cabs.. This product works best with fiberglass shells that are 1/8" to 3/16" thick. Please note that both openings must be exactly the same size for this boot to fit properly.
$13.90 per foot
In Stock
Order 544
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Accordion Boot 15 - Part Number 546
The Accordion Boot 15 is designed applications where you have a large gap between the space you want to seal. This product works best with fiberglass shells or sheet metal flange that are 1/8" to 3/16" thick. Both openings must be exactly the same size for this boot to fit properly.
$16.50 per foot
In Stock
Order 546
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Compression Bulb Seal - Part Number 545
Use this seal when you leave the rear slider window in the truck. This product works best with fiberglass shells that are 1/8" to 3/16" thick. You will also use this boot if the opening in the fiberglass shell is much larger than the opening in your truck.
$8.25 per foot
In Stock
Order 545
- Enter the total amount of feet of boot material you need in the text box
- Check your entries, then click on the "Order Now" button.
Frequently Asked Questions
- What is the purpose of a camper window seal boot?
A camper window seal bootprovides a sealed, flexible connection between the cab and camper shell, allowing access and preventing leaks, dust, and wind from entering.
- Will the Accordion Boot or Compression Boot Gasket Material work if my fiberglass shell opening is bigger than my truck window?
In order for the accordion boot to work, both openings must be the exact size. If the fiberglass shell opening is larger, use the compression boot instead.
- I am getting a camper shell with a sliding glass window so I am taking the window out of my pickup and it looks like the Compression Boot would be what i need, I am wondering which is the best to get the Compression Boot - Part Number 540 or the Compression Bulb Seal - Part Number 545?
Both boot function the same. We carry both types as different cap manufacturers will use one or the other. But there are slight differences between the two styles.
The flap seal 540 is a single layer of rubber that presses against the cab. In order to seal the edge is a single straight flat edge.
The bulb seal 545 is different in this way. It has a rounded edge. the rubber is double walled with an empty cavity. The material is slightly softer and will conform to the shape of the truck.
Both seal perform similarly. When it come to which one it is really a matter of preference.
